Beaver G50 Stainless Steel Screw Pin Dee Shackle 5t
SMSWI16per Each
$657.64 inc GSTTrade $591.88, save $65.76Trade accounts save 10%. Apply with your ABN
| WLL | 5t |
| Size | 16mm x 19mm |
| Type | Grade 50 |
| Shape | Dee |
| Weight | 0.36kg |
| Diameter | 25mm |
| Closing Method | Screw Pin |
| Inside Width (W) | 50mm |
| Pin Diameter (D) | 27mm |
| Diameter Boss (F) | 50mm |
| Inside Length (L) | 100mm |
| Working Load Limit | 5t |
About this product
The Beaver G50 Stainless Steel Screw Pin Dee Shackle is a 5t rated shackle for lifting in wet and corrosive conditions. At 16mm x 19mm with a 27mm pin, it is the largest capacity in the range, giving you a 50mm inside width and 100mm inside length to work with. Grade 50 material, made from Grade 316 stainless steel, so it handles salt air and washdown far better than a galvanised shackle. Complies to AS 4791.
The screw pin closing method means you can pull it apart by hand and move it to the next lift, which suits changeover work rather than a permanent connection. Weight is 0.36kg, so it is easy to handle up high. Common jobs include marine rigging, water treatment plants and food processing sites. Check the pin threads and the boss for wear before each lift.
Common questions
- what is the WLL of a 16mm stainless dee shackle
- This Beaver G50 shackle has a 5t working load limit at 16mm x 19mm.
- is the beaver g50 dee shackle stainless steel
- Yes, it is made from Grade 316 stainless steel for high corrosion resistance.
- screw pin or bolt type shackle for lifting
- A screw pin like this one comes apart by hand and suits non-permanent rigging where the shackle gets moved between lifts.
Full specifications
| Product Code | Size | WLL | Type | Shape | Closing Method | Weight |
|---|---|---|---|---|---|---|
| SMSWI16 | 16mm x 19mm | 5t | Grade 50 | Dee | Screw Pin | 0.36kg |
| Product Code | Size | Diameter | Pin Diameter (D) | Inside Width (W) | Inside Length (L) | Diameter Boss (F) |
|---|---|---|---|---|---|---|
| SMSWI16 | 16mm x 19mm | 25mm | 27mm | 50mm | 100mm | 50mm |
Questions about this equipment? Send us a message and we’ll check it against the job.
