Beaver Jax Bottle Jack 20t
JAX020per Each
$236.38 inc GSTTrade $212.74, save $23.64Trade accounts save 10%. Apply with your ABN
| Capacity | 20t |
About this product
The Beaver Jax Bottle Jack 20t is a hydraulic lifting jack for raising heavy loads off the ground on site or in the workshop. It is the 20t capacity option in the Beaver Jax range, so it suits the bigger gear, trucks, plant and industrial lifts where the smaller jacks in the range run out of grunt. Heavy duty steel construction throughout, with a wide base that keeps the jack stable under load.
Built for automotive, industrial and construction work, and it complies to AS/NZS 2693. Sit it on firm, level ground before you start pumping, and always support the load on stands once it is up. Keep the ram clean and wound down when it is not in use, and check the seals for weeping oil before each job. Handled properly, a 20t bottle jack will earn its keep for years.
Common questions
- how much can a 20t bottle jack lift
- This one is rated at 20t capacity. Stay within that rating and never work under a load that is only held by the jack.
- is the beaver jax bottle jack australian standards approved
- Yes, the Beaver Jax Bottle Jack complies to AS/NZS 2693.
- what is the beaver jax bottle jack made of
- Heavy duty steel construction with a wide base for stability under load.
- what is a 20t bottle jack used for
- Automotive, industrial and construction lifting where you need serious capacity in a compact hydraulic jack.
Full specifications
| Product Code | Description | Capacity Tonnes | D mm | D2 mm | H2 mm | W mm | Screw Adjusting Height mm | Lift Height mm | Minimum Height H minimum mm | Maximum Height H maximum (kg) | Weight (kg) | UOM |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Jax004 | Bottle Jack | 4 | 70 | 29 | 80 | 136 | 70 | 125 | 212 | 407 | 4.7 | Each |
| Jax006 | Bottle Jack | 6 | 75 | 32 | 79 | 167 | 80 | 145 | 230 | 455 | 5.7 | Each |
| Jax008 | Bottle Jack | 8 | 85 | 40 | 79 | 154 | 80 | 150 | 228 | 458 | 5.8 | Each |
| Jax010 | Bottle Jack | 10 | 94 | 43 | 79 | 169 | 80 | 150 | 229 | 459 | 7.1 | Each |
| Jax015 | Bottle Jack | 15 | 110 | 45 | 82 | 188 | 60 | 155 | 240 | 455 | 8.6 | Each |
| Jax020 | Bottle Jack | 20 | 140 | 69 | 95 | 308 | - | 165 | 260 | 425 | 17.8 | Each |
Questions about this equipment? Send us a message and we’ll check it against the job.
