Donaghys Winchline Rope 12mm
D4BRS12WAMper Metre
$19.52 inc GSTTrade $17.57, save $1.95Trade accounts save 10%. Apply with your ABN
| Rope Diameter | 12mm |
About this product
The Donaghys Winchline Rope 12mm is a synthetic winch line built from ultra high molecular weight polyethylene fibres, made for vehicle recovery, towing and pulling or stringing jobs. At 12mm it sits in the lighter end of the range, handy where you want a line you can pull out and re-spool by hand without wrestling it. The UHMwPE fibre runs 8 times lighter and 70% stronger than steel wire rope, with tenacity up to 15 times that of steel and low elongation of 4% at break.
The braid is coated with Donaghys Armorcoat, so it stands up to abrasion inside and out. It floats, does not absorb water and holds up well under UV. The build is non rotational, and the pink colour makes the line easy to spot on the ground or in the bush. Covers and fittings can be added to suit the application.
Common questions
- is 12mm winchline strong enough to replace wire rope
- Donaghys winchline is made from UHMwPE fibre that is 70% stronger and 8 times lighter than steel wire rope, with tenacity up to 15 times that of steel. Match the size to your winch and rated load requirements.
- what is donaghys winchline made of
- High strength ultra high molecular weight polyethylene (UHMwPE) fibres, braided and coated with Donaghys Armorcoat for internal and external abrasion resistance.
- does synthetic winch rope float in water
- Yes. The fibre density is very low, so the rope floats and does not absorb water, which suits recovery work in creek crossings and wet ground.
Full specifications
| Diameter | Break Force | Max Length | kg/100m |
|---|---|---|---|
| 9mm | 9.7t | 1025m | 4kg/100m |
| 12mm | 17.5t | 3050m | 7.8kg/100m |
| 14mm | 21.2t | 2250m | 10.5kg/100m |
| 16mm | 26t | 1720m | 12kg/100m |
| 18mm | 33t | 1360m | 17kg/100m |
| 20mm | 38.8t | 1100m | 20kg/100m |
| 22mm | 47t | 904m | 25kg/100m |
| 24mm | 55t | 760m | 29kg/100m |
| 26mm | 64.5t | 650m | 34kg/100m |
| 32mm | 84.6t | 1189m | 52kg/100m |
| 36mm | 106t | 939m | 60kg/100m |
| 44mm | 157t | 629m | 81kg/100m |
Questions about this equipment? Send us a message and we’ll check it against the job.
