Weld On Anchor Point 21kN
BSC5026per Each
$64.95 inc GSTTrade $58.46, save $6.49Trade accounts save 10%. Apply with your ABN
| Rating | 21kN |
About this product
The Weld On Anchor Point 21kN is a fixed attachment point you weld straight onto steel structure to give workers a permanent place to clip on. At 21kN it is the higher-rated of the two sizes in the B-SAFE-V range, so it is the one to reach for where the anchor needs to carry more load than the 15kN version.
Welding it on means there is nothing to come loose and no holes to drill through structural steel. B-Safe list mining, offshore exploration, road or rail transport and maritime work among the applications, which covers most places where an anchor stays put for the life of the asset. Position it where the welder can get a full run all the way around, and check the weld and the point itself as part of your regular height safety inspections.
Common questions
- what is the 21kN weld on anchor point rated for
- It is rated at 21kN. That is the higher of the two ratings offered, with a 15kN version also available in the same range.
- difference between 15kN and 21kN weld on anchor point
- Same weld-on design, different rating. The 21kN suits situations where you need the higher-rated anchor, the 15kN covers lighter duty applications.
- where can you use a weld on anchor point
- Anywhere you have suitable steel to weld to. B-Safe list mining, offshore exploration, road or rail transport and maritime industries as typical applications.
Full specifications
| Product code | WLL | A | B | C | D | E | F | G | I | M | Rating (Person) | Approx Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BSC5024 | 1.5t | 38mm | 79mm | 66mm | 14mm | 13.5mm | 32mm | 25mm | 31mm | 2mm | 15kN | 0.4kg |
| BSC5026 | 2.5t | 45mm | 92.5mm | 77mm | 16mm | 13.5mm | 36mm | 27mm | 38mm | 3.5mm | 21kN | 0.6kg |
