Beaver Jax Squat Bottle Jack 12t
BJS012per Each
$114.89 inc GSTTrade $103.40, save $11.49Trade accounts save 10%. Apply with your ABN
| UOM | Each |
| D mm | 95 |
| W mm | 141 |
| D2 mm | 43 |
| H2 mm | 98 |
| Capacity | 12t |
| Description | Squat Bottle Jack |
| Weight (kg) | 6.3 |
| Lift Height mm | 110 |
| Capacity Tonnes | 12 |
| Screw Adjusting Height mm | 60 |
| Minimum Height H minimum mm | 190 |
| Maximum Height H maximum (kg) | 360 |
About this product
The Beaver Jax Squat Bottle Jack 12t is a low profile steel bottle jack for lifting heavy gear where there is barely any clearance underneath. At 190mm minimum height it slides in under a chassis or a machine frame that a standard bottle jack will not fit. From there you get 110mm of ram lift plus 60mm on the adjustable centre screw, taking it out to a maximum height of 360mm.
The 12t rating is the smaller of the two capacities in the range, so it suits the lighter end of truck, plant and workshop work without carrying the extra bulk. Heavy duty steel construction throughout, 6.3kg in the hand, with a 95mm by 141mm base. Used across automotive, industrial and construction work. Complies to AS/NZS 2693.
Common questions
- how much can a Beaver 12t squat bottle jack lift
- It is rated at 12 tonnes. Beaver's squat bottle jack range covers 12 to 20 tonne lifts, and this is the 12t size.
- what is the minimum height of the Beaver Jax squat bottle jack 12t
- Minimum height is 190mm, which is why it works where ground clearance is tight. Maximum height is 360mm.
- how far does the 12t squat bottle jack lift
- You get 110mm of ram lift, plus another 60mm from the adjustable centre screw if you need to close the gap before pumping.
Full specifications
| Product Code | Description | Capacity Tonnes | D mm | D2 mm | H2 mm | W mm | Screw Adjusting Height mm | Lift Height mm | Minimum Height H minimum mm | Maximum Height H maximum (kg) | Weight (kg) | UOM |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BJS012 | Squat Bottle Jack | 12 | 95 | 43 | 98 | 141 | 60 | 110 | 190 | 360 | 6.3 | Each |
| BJS020 | Squat Bottle Jack | 20 | 110 | 50 | 98 | 152 | 65 | 105 | 195 | 365 | 9.1 | Each |
Questions about this equipment? Send us a message and we’ll check it against the job.
