Beaver Liftall Single Phase Electric Hoists 3t x 6m
BEL1306STper Each
POA — add it to your list and we’ll sort you out.
| A | 249mm |
| B | 249mm |
| C | 180mm |
| D | 134mm |
| E | 41mm |
| F | 760mm |
| G | 790mm |
| H | 360mm |
| Lift Height | 6m |
| Rated Capacity | 3t |
| Lift Height (m) | 6 |
| Test Load Tonne | 3.75 |
| Output (kw) 7.60Hz | 1.2 |
| Rated Capacity (kg) | 3000 |
| Std Pendant Length (m) | 5 |
| Load CHain No. of Falls | 3 |
| Min. Weight (kg) Approx | 90 |
| Load Chain Diameter (mm) | 7.0 |
| Min Headroom G (mm) Max. | 790 |
| Lifting Speed (m/min) 50Hz | 1.3 |
| Hoist Motor Single Phase% ED | 40 |
| Hoist Motor Single PhaseIns Class | E |
About this product
The Beaver Liftall Single Phase Electric Hoists 3t x 6m is a 240 volt, 50Hz chain hoist for lifting heavy loads off a fixed suspension point. This is the top of the range at 3 tonne, the heaviest capacity Beaver offers in the single phase Liftall series, running 7.0mm plated European load chain over three falls to a 6m lift height. Lifting speed is 1.3m/min at 50Hz from a 1.2kW motor, and the unit weighs around 90kg with 790mm maximum headroom.
All-steel construction, fully enclosed, with an IP54 rating. An overload protection clutch is built in, and upper and lower electrical limit switches stop the hook at the end of travel. It comes with a top suspension hook and a 5m pendant, so you can stand clear of the load while lifting. Test load is 3.75 tonne and a test certificate is supplied, along with a manual covering wiring and parts. Complies to AS1418.2.
Common questions
- what is the lifting capacity of the BEL1306ST beaver hoist
- Rated capacity is 3 tonne, or 3000kg, which is the largest in the Beaver Liftall single phase range. Test load is 3.75 tonne.
- does the beaver liftall 3t hoist run on 240v single phase
- Yes, it runs on 240 volt, 50Hz single phase power. The motor output is 1.2kW with 40% ED and Class E insulation.
- how fast does a 3 tonne beaver electric chain hoist lift
- Lifting speed is 1.3m per minute at 50Hz. The 3t model uses three falls of 7.0mm load chain to reach the 6m lift height.
Full specifications
| Product Code | Rated Capacity (kg) | Lift Height (m) | Lifting Speed (m/min) 50Hz | Output (kw) 7.60Hz | Hoist Motor Single PhaseIns Class | Hoist Motor Single Phase% ED | Load Chain Diameter (mm) | Load CHain No. of Falls | Test Load Tonne | Min Headroom G (mm) Max. | Min. Weight (kg) Approx | Std Pendant Length (m) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BEL1053S | 500 | 3 | 5 | 0.6 | E | 40 | 7.0 | 1 | 0.625 | 545 | 64 | 2 |
| BEL1056S | 500 | 6 | 5 | 0.6 | E | 40 | 7.0 | 1 | 0.625 | 545 | 68 | 5 |
| BEL1103S | 1000 | 3 | 5 | 1.2 | E | 40 | 7.0 | 1 | 1.25 | 595 | 65 | 2 |
| BEL1106S | 1000 | 6 | 5 | 1.2 | E | 40 | 7.0 | 1 | 1.25 | 595 | 69 | 5 |
| BEL1203SD | 2000 | 3 | 2.5 | 1.2 | E | 40 | 7.0 | 2 | 2.5 | 700 | 72 | 2 |
| BEL1206SD | 2000 | 6 | 2.5 | 1.2 | E | 40 | 7.0 | 2 | 2.5 | 700 | 79 | 5 |
| BEL1303ST | 3000 | 3 | 1.3 | 1.2 | E | 40 | 7.0 | 3 | 3.75 | 790 | 80 | 2 |
| BEL1306ST | 3000 | 6 | 1.3 | 1.2 | E | 40 | 7.0 | 3 | 3.75 | 790 | 90 | 5 |
| Product Code | Rated Capacity | A | B | C | D | E | F | G | H |
|---|---|---|---|---|---|---|---|---|---|
| BEL1053S | 0.5t | 249mm | 249mm | 168mm | 146mm | 25mm | 565mm | 545mm | 195mm |
| BEL1056S | 0.5t | 249mm | 249mm | 168mm | 146mm | 25mm | 565mm | 545mm | 195mm |
| BEL1103S | 1t | 249mm | 249mm | 168mm | 146mm | 30mm | 614mm | 545mm | 195mm |
| BEL1106S | 1t | 249mm | 249mm | 168mm | 146mm | 30mm | 614mm | 545mm | 195mm |
| BEL1203SD | 2t | 249mm | 249mm | 180mm | 134mm | 33mm | 665mm | 700mm | 235mm |
| BEL1206SD | 2t | 249mm | 249mm | 180mm | 134mm | 33mm | 665mm | 700mm | 235mm |
| BEL1303ST | 3t | 249mm | 249mm | 180mm | 134mm | 41mm | 760mm | 790mm | 360mm |
| BEL1306ST | 3t | 249mm | 249mm | 180mm | 134mm | 41mm | 760mm | 790mm | 360mm |
