Beaver Liftall Single Phase Electric Hoists 3t x 3m
BEL1303STper Each
POA — add it to your list and we’ll sort you out.
| A | 249mm |
| B | 249mm |
| C | 180mm |
| D | 134mm |
| E | 41mm |
| F | 760mm |
| G | 790mm |
| H | 360mm |
| Lift Height | 3m |
| Rated Capacity | 3t |
| Lift Height (m) | 3 |
| Test Load Tonne | 3.75 |
| Output (kw) 7.60Hz | 1.2 |
| Rated Capacity (kg) | 3000 |
| Std Pendant Length (m) | 2 |
| Load CHain No. of Falls | 3 |
| Min. Weight (kg) Approx | 80 |
| Load Chain Diameter (mm) | 7.0 |
| Min Headroom G (mm) Max. | 790 |
| Lifting Speed (m/min) 50Hz | 1.3 |
| Hoist Motor Single Phase% ED | 40 |
| Hoist Motor Single PhaseIns Class | E |
About this product
The Beaver Liftall Single Phase Electric Hoist in 3t x 3m is the top of the range for capacity, running off standard 240 volt, 50Hz single phase power so you can lift 3000kg without a three phase supply. The 7.0mm plated European load chain runs three falls, which gives you the extra capacity but slows the lift to 1.3m/min at 50Hz. Test load is 3.75 tonne and the 1.2kw motor is rated at 40% ED, insulation class E.
All-steel enclosed construction, IP54 rated, with an overload protection clutch and upper and lower electrical limit switches. Minimum headroom is 790mm and the unit weighs around 80kg, so plan your suspension point before it goes up. Supplied with a top suspension hook, a 2m pendant, a test certificate and a manual with wiring diagrams and parts breakdown. Complies to AS1418.2.
Common questions
- what power supply does the beaver 3t electric chain hoist need
- It runs on 240 volt, 50Hz single phase power. The hoist motor draws 1.2kw output and is rated at 40% ED.
- how fast does the beaver liftall 3 tonne hoist lift
- 1.3m per minute at 50Hz. The three falls of load chain give it the 3t capacity, which is why it is slower than the lighter models in the range.
- how much headroom do i need for the beaver 3t x 3m hoist
- Minimum headroom is 790mm. Allow for the weight too, the hoist is approximately 80kg before you add the load.
Full specifications
| Product Code | Rated Capacity (kg) | Lift Height (m) | Lifting Speed (m/min) 50Hz | Output (kw) 7.60Hz | Hoist Motor Single PhaseIns Class | Hoist Motor Single Phase% ED | Load Chain Diameter (mm) | Load CHain No. of Falls | Test Load Tonne | Min Headroom G (mm) Max. | Min. Weight (kg) Approx | Std Pendant Length (m) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BEL1053S | 500 | 3 | 5 | 0.6 | E | 40 | 7.0 | 1 | 0.625 | 545 | 64 | 2 |
| BEL1056S | 500 | 6 | 5 | 0.6 | E | 40 | 7.0 | 1 | 0.625 | 545 | 68 | 5 |
| BEL1103S | 1000 | 3 | 5 | 1.2 | E | 40 | 7.0 | 1 | 1.25 | 595 | 65 | 2 |
| BEL1106S | 1000 | 6 | 5 | 1.2 | E | 40 | 7.0 | 1 | 1.25 | 595 | 69 | 5 |
| BEL1203SD | 2000 | 3 | 2.5 | 1.2 | E | 40 | 7.0 | 2 | 2.5 | 700 | 72 | 2 |
| BEL1206SD | 2000 | 6 | 2.5 | 1.2 | E | 40 | 7.0 | 2 | 2.5 | 700 | 79 | 5 |
| BEL1303ST | 3000 | 3 | 1.3 | 1.2 | E | 40 | 7.0 | 3 | 3.75 | 790 | 80 | 2 |
| BEL1306ST | 3000 | 6 | 1.3 | 1.2 | E | 40 | 7.0 | 3 | 3.75 | 790 | 90 | 5 |
| Product Code | Rated Capacity | A | B | C | D | E | F | G | H |
|---|---|---|---|---|---|---|---|---|---|
| BEL1053S | 0.5t | 249mm | 249mm | 168mm | 146mm | 25mm | 565mm | 545mm | 195mm |
| BEL1056S | 0.5t | 249mm | 249mm | 168mm | 146mm | 25mm | 565mm | 545mm | 195mm |
| BEL1103S | 1t | 249mm | 249mm | 168mm | 146mm | 30mm | 614mm | 545mm | 195mm |
| BEL1106S | 1t | 249mm | 249mm | 168mm | 146mm | 30mm | 614mm | 545mm | 195mm |
| BEL1203SD | 2t | 249mm | 249mm | 180mm | 134mm | 33mm | 665mm | 700mm | 235mm |
| BEL1206SD | 2t | 249mm | 249mm | 180mm | 134mm | 33mm | 665mm | 700mm | 235mm |
| BEL1303ST | 3t | 249mm | 249mm | 180mm | 134mm | 41mm | 760mm | 790mm | 360mm |
| BEL1306ST | 3t | 249mm | 249mm | 180mm | 134mm | 41mm | 760mm | 790mm | 360mm |
