Beaver Liftall Single Phase Electric Hoists 2t x 6m
BEL1206SDper Each
POA — add it to your list and we’ll sort you out.
| A | 249mm |
| B | 249mm |
| C | 180mm |
| D | 134mm |
| E | 33mm |
| F | 665mm |
| G | 700mm |
| H | 235mm |
| Lift Height | 6m |
| Rated Capacity | 2t |
| Lift Height (m) | 6 |
| Test Load Tonne | 2.5 |
| Output (kw) 7.60Hz | 1.2 |
| Rated Capacity (kg) | 2000 |
| Std Pendant Length (m) | 5 |
| Load CHain No. of Falls | 2 |
| Min. Weight (kg) Approx | 79 |
| Load Chain Diameter (mm) | 7.0 |
| Min Headroom G (mm) Max. | 700 |
| Lifting Speed (m/min) 50Hz | 2.5 |
| Hoist Motor Single Phase% ED | 40 |
| Hoist Motor Single PhaseIns Class | E |
About this product
The Beaver Liftall Single Phase Electric Hoist 2t x 6m is a 240 volt chain hoist for lifting loads up to 2000kg off a standard single phase supply. The 6m lift height suits workshop bays and maintenance jobs where you need decent hook travel without going to three phase power. It runs two falls of 7.0mm plated European load chain, lifts at 2.5m/min on 50Hz, and is driven by a 1.2kW motor. Test load is 2.5 tonne.
All-steel and fully enclosed, with an IP54 rating and a built-in overload protection clutch. Upper and lower electrical limit switches stop the hook at both ends of travel. Minimum headroom is 700mm, the pendant lead is 5m, and it weighs around 79kg with a top suspension hook fitted. Complies to AS1418.2, and a test certificate and manual come with it.
Common questions
- what can a 2t beaver liftall electric chain hoist lift
- It is rated to 2000kg, or 2 tonne, and is tested at 2.5 tonne. An overload protection clutch is built in to guard against lifting past the rating.
- does the beaver liftall 2t hoist run on single phase power
- Yes, it runs on 240 volt, 50Hz single phase supply, so you do not need a three phase outlet. Motor output is 1.2kW.
- how much headroom do i need for the beaver liftall 2t x 6m hoist
- Minimum headroom is 700mm at the maximum. Lift height is 6m as standard, with longer lifts available on request.
Full specifications
| Product Code | Rated Capacity (kg) | Lift Height (m) | Lifting Speed (m/min) 50Hz | Output (kw) 7.60Hz | Hoist Motor Single PhaseIns Class | Hoist Motor Single Phase% ED | Load Chain Diameter (mm) | Load CHain No. of Falls | Test Load Tonne | Min Headroom G (mm) Max. | Min. Weight (kg) Approx | Std Pendant Length (m) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BEL1053S | 500 | 3 | 5 | 0.6 | E | 40 | 7.0 | 1 | 0.625 | 545 | 64 | 2 |
| BEL1056S | 500 | 6 | 5 | 0.6 | E | 40 | 7.0 | 1 | 0.625 | 545 | 68 | 5 |
| BEL1103S | 1000 | 3 | 5 | 1.2 | E | 40 | 7.0 | 1 | 1.25 | 595 | 65 | 2 |
| BEL1106S | 1000 | 6 | 5 | 1.2 | E | 40 | 7.0 | 1 | 1.25 | 595 | 69 | 5 |
| BEL1203SD | 2000 | 3 | 2.5 | 1.2 | E | 40 | 7.0 | 2 | 2.5 | 700 | 72 | 2 |
| BEL1206SD | 2000 | 6 | 2.5 | 1.2 | E | 40 | 7.0 | 2 | 2.5 | 700 | 79 | 5 |
| BEL1303ST | 3000 | 3 | 1.3 | 1.2 | E | 40 | 7.0 | 3 | 3.75 | 790 | 80 | 2 |
| BEL1306ST | 3000 | 6 | 1.3 | 1.2 | E | 40 | 7.0 | 3 | 3.75 | 790 | 90 | 5 |
| Product Code | Rated Capacity | A | B | C | D | E | F | G | H |
|---|---|---|---|---|---|---|---|---|---|
| BEL1053S | 0.5t | 249mm | 249mm | 168mm | 146mm | 25mm | 565mm | 545mm | 195mm |
| BEL1056S | 0.5t | 249mm | 249mm | 168mm | 146mm | 25mm | 565mm | 545mm | 195mm |
| BEL1103S | 1t | 249mm | 249mm | 168mm | 146mm | 30mm | 614mm | 545mm | 195mm |
| BEL1106S | 1t | 249mm | 249mm | 168mm | 146mm | 30mm | 614mm | 545mm | 195mm |
| BEL1203SD | 2t | 249mm | 249mm | 180mm | 134mm | 33mm | 665mm | 700mm | 235mm |
| BEL1206SD | 2t | 249mm | 249mm | 180mm | 134mm | 33mm | 665mm | 700mm | 235mm |
| BEL1303ST | 3t | 249mm | 249mm | 180mm | 134mm | 41mm | 760mm | 790mm | 360mm |
| BEL1306ST | 3t | 249mm | 249mm | 180mm | 134mm | 41mm | 760mm | 790mm | 360mm |
Questions about this equipment? Send us a message and we’ll check it against the job.
