Beaver Liftall Single Phase Electric Hoists 0.5t x 3m
BEL1053Sper Each
POA — add it to your list and we’ll sort you out.
| A | 249mm |
| B | 249mm |
| C | 168mm |
| D | 146mm |
| E | 25mm |
| F | 565mm |
| G | 545mm |
| H | 195mm |
| Lift Height | 3m |
| Rated Capacity | 0.5t |
| Lift Height (m) | 3 |
| Test Load Tonne | 0.625 |
| Output (kw) 7.60Hz | 0.6 |
| Rated Capacity (kg) | 500 |
| Std Pendant Length (m) | 2 |
| Load CHain No. of Falls | 1 |
| Min. Weight (kg) Approx | 64 |
| Load Chain Diameter (mm) | 7.0 |
| Min Headroom G (mm) Max. | 545 |
| Lifting Speed (m/min) 50Hz | 5 |
| Hoist Motor Single Phase% ED | 40 |
| Hoist Motor Single PhaseIns Class | E |
About this product
The Beaver Liftall Single Phase Electric Hoist 0.5t x 3m is a 240 volt, 50Hz chain hoist for lifting loads up to 500kg through a 3m lift. It is the lightest size in the range at roughly 64kg, so it is the easy one to shift between jobs, and the single fall of 7.0mm plated European load chain keeps the reeving simple. Lifting speed is 5m/min from a 0.6kW motor, with a 2m standard pendant.
All-steel construction, fully enclosed, with an IP54 rating and Class E insulation on the motor at 40% ED. Overload protection is built in through a clutch, and upper and lower electrical limit switches stop the chain running out at either end. Minimum headroom is 545mm, tested to 0.625 tonne, and it comes with a top suspension hook, a test certificate and a manual with wiring diagrams and parts breakdown. Complies to AS1418.2.
Common questions
- how much can the beaver liftall 0.5t electric hoist lift
- It is rated to 500kg, or 0.5 tonne, on a single fall of chain. Test load is 0.625 tonne.
- does the beaver liftall single phase hoist run on 240v
- Yes, it is a 240 volt, 50Hz single phase hoist, so it will run off standard single phase power.
- what headroom do i need for a beaver 0.5t x 3m chain hoist
- Minimum headroom is 545mm at maximum. It is supplied with a top suspension hook for hanging off a beam clamp or trolley.
Full specifications
| Product Code | Rated Capacity (kg) | Lift Height (m) | Lifting Speed (m/min) 50Hz | Output (kw) 7.60Hz | Hoist Motor Single PhaseIns Class | Hoist Motor Single Phase% ED | Load Chain Diameter (mm) | Load CHain No. of Falls | Test Load Tonne | Min Headroom G (mm) Max. | Min. Weight (kg) Approx | Std Pendant Length (m) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BEL1053S | 500 | 3 | 5 | 0.6 | E | 40 | 7.0 | 1 | 0.625 | 545 | 64 | 2 |
| BEL1056S | 500 | 6 | 5 | 0.6 | E | 40 | 7.0 | 1 | 0.625 | 545 | 68 | 5 |
| BEL1103S | 1000 | 3 | 5 | 1.2 | E | 40 | 7.0 | 1 | 1.25 | 595 | 65 | 2 |
| BEL1106S | 1000 | 6 | 5 | 1.2 | E | 40 | 7.0 | 1 | 1.25 | 595 | 69 | 5 |
| BEL1203SD | 2000 | 3 | 2.5 | 1.2 | E | 40 | 7.0 | 2 | 2.5 | 700 | 72 | 2 |
| BEL1206SD | 2000 | 6 | 2.5 | 1.2 | E | 40 | 7.0 | 2 | 2.5 | 700 | 79 | 5 |
| BEL1303ST | 3000 | 3 | 1.3 | 1.2 | E | 40 | 7.0 | 3 | 3.75 | 790 | 80 | 2 |
| BEL1306ST | 3000 | 6 | 1.3 | 1.2 | E | 40 | 7.0 | 3 | 3.75 | 790 | 90 | 5 |
| Product Code | Rated Capacity | A | B | C | D | E | F | G | H |
|---|---|---|---|---|---|---|---|---|---|
| BEL1053S | 0.5t | 249mm | 249mm | 168mm | 146mm | 25mm | 565mm | 545mm | 195mm |
| BEL1056S | 0.5t | 249mm | 249mm | 168mm | 146mm | 25mm | 565mm | 545mm | 195mm |
| BEL1103S | 1t | 249mm | 249mm | 168mm | 146mm | 30mm | 614mm | 545mm | 195mm |
| BEL1106S | 1t | 249mm | 249mm | 168mm | 146mm | 30mm | 614mm | 545mm | 195mm |
| BEL1203SD | 2t | 249mm | 249mm | 180mm | 134mm | 33mm | 665mm | 700mm | 235mm |
| BEL1206SD | 2t | 249mm | 249mm | 180mm | 134mm | 33mm | 665mm | 700mm | 235mm |
| BEL1303ST | 3t | 249mm | 249mm | 180mm | 134mm | 41mm | 760mm | 790mm | 360mm |
| BEL1306ST | 3t | 249mm | 249mm | 180mm | 134mm | 41mm | 760mm | 790mm | 360mm |
