Beaver G80 Weld-On Safety Excavator Hook 3t
886703Aper Each
$33.91 inc GSTTrade $30.52, save $3.39Trade accounts save 10%. Apply with your ABN
| b | 106mm |
| g | 30.5mm |
| w | 36mm |
| L1 | 129mm |
| L2 | 86mm |
| WLL | 3t |
| Approx Weight | 1.2kg |
| Working Load Limit | 3t |
About this product
The Beaver G80 Weld-On Safety Excavator Hook 3t is a weld-on hook with a safety latch, made to create a permanent lifting or tie down point once it is welded on securely. This 3t size sits in the mid range of the four, with a 30.5mm opening, 36mm width and a 106mm body dimension. Lengths run 129mm and 86mm, and it weighs roughly 1.2kg, so it adds very little to the structure it is fitted to.
Common jobs include excavator bucket lifting points, spreader beam attachments and fixed anchor points. The safety latch gives positive locking and keeps the load in line with the hook. Beaver Grade 80 components are made from heat treated alloy steel, with quality testing carried out through manufacture and distinguishing marks for identification. Complies to AS 3776.
Common questions
- what is the WLL of the beaver 3t weld on excavator hook
- The working load limit is 3t. It is one of four sizes in the Beaver G80 weld-on safety excavator hook range.
- what is the beaver g80 excavator hook made of
- Heat treated alloy steel, in line with Beaver Grade 80 lifting components. Quality testing is carried out throughout manufacture and the hook carries distinguishing marks for identification.
- can you use a weld on excavator hook as a tie down point
- Yes, once the hook is welded on securely it can serve as a fixed anchor or tie down point, as well as an excavator bucket lifting point or spreader beam attachment.
Full specifications
| Product code | WLL | b | g | L1 | L2 | w | Approx Weight |
|---|---|---|---|---|---|---|---|
| 886701A | 1t | 53mm | 18mm | 87mm | 55mm | 20mm | 0.35kg |
| 886703A | 3t | 106mm | 30.5mm | 129mm | 86mm | 36mm | 1.2kg |
| 886705A | 5t | 133mm | 34mm | 171mm | 118.5mm | 43.5mm | 2.46kg |
| 886708A | 8t | 136.5mm | 34mm | 177mm | 118.5mm | 51mm | 3.26kg |
| 886710A | 10t | 169.5mm | 51mm | 223mm | 154mm | 53mm | 5.17kg |
