Beaver G80 Eye Shortening Grab Hook 6mm
885306per Each
$4.98 inc GSTTrade $4.48, save $0.50Trade accounts save 10%. Apply with your ABN
| b | 45.8mm |
| e | 51mm |
| g | 8.3mm |
| d1 | 13.5mm |
| d2 | 8mm |
| WLL | 1.1t |
| Chain Size | 6mm |
| Approx Weight | 0.14kg |
About this product
The Beaver G80 Eye Shortening Grab Hook 6mm is used to shorten a chain sling leg quickly without losing rated capacity, and it is the smallest hook in the range. Matched to 6mm chain with a working load limit of 1.1t, it suits light chain slings where you still need proper rated gear. The eye at the top takes a coupler, shackle or wire rope sling, so it drops into existing assemblies easily.
Supporting lugs sit either side of the throat to hold the chain link square and stop deformation that would cut the WLL. Built from heat treated alloy steel and complies to AS 3776, with identification marks stamped on the body. Eye dimensions are 13.5mm by 8mm, throat 8.3mm, and it weighs around 0.14kg. Do not tip load it.
Common questions
- what is the WLL of a 6mm G80 grab hook
- This Beaver G80 Eye Shortening Grab Hook is rated at a 1.1t working load limit on 6mm Grade 80 chain.
- can you tip load an eye grab hook
- No. Eye grab hooks are not suitable for tip loading, so the chain link must seat properly in the throat against the supporting lugs.
- what chain size does the beaver 885306 grab hook fit
- It is made for 6mm chain, with a 8.3mm throat and eye dimensions of 13.5mm by 8mm. Larger chain sizes are available in the same range.
Full specifications
| Product code | Chain Size | WLL | e | b | d1 | d2 | g | Approx Weight |
|---|---|---|---|---|---|---|---|---|
| 885306 | 6mm | 1.1t | 51mm | 45.8mm | 13.5mm | 8mm | 8.3mm | 0.14kg |
| 885307 | 7-8mm | 2t | 61.7mm | 51mm | 18mm | 9.5mm | 10.8mm | 0.35kg |
| 885310 | 10mm | 3.2t | 80mm | 70mm | 20.5mm | 13mm | 13.5mm | 0.65kg |
| 885313 | 13mm | 5.3t | 99.7mm | 89.7mm | 26mm | 15.5mm | 16.5mm | 1.39kg |
| 885316 | 16mm | 8t | 105.5mm | 113mm | 30.5mm | 19mm | 20mm | 2.1kg |
| 885320 | 20mm | 12.5t | 140.7mm | 143mm | 37.5mm | 23mm | 25mm | 4kg |
| 885322 | 22mm | 15t | 165mm | 160.5mm | 44mm | 26mm | 28mm | 6.36kg |
| 885326 | 26mm | 21.2t | 188.5mm | 181.3mm | 44mm | 34mm | 30mm | 9.6kg |
| 885332 | 32mm | 31.5t | 230mm | 223mm | 57mm | 40mm | 38mm | 19.4kg |
