Beaver G2070 Galvanised Wire Rope - 7x19 8mm
712408per Each
$2.55 inc GSTTrade $2.30, save $0.25Trade accounts save 10%. Apply with your ABN
| Lay | RHOL |
| MBF | 43.5kN |
| Core | Wire |
| Grade | 2070 |
| Finish | Galvanised |
| Approx Mass | 24.4kg/100m |
| Construction | 7x19 |
| Wire Diameter | 8mm |
About this product
Beaver G2070 Galvanised Wire Rope - 7x19 8mm is a flexible general purpose rope for winching, hauling and static rigging work where you need a rope that bends without kinking. The 8mm diameter sits in the middle of the range, giving you a 43.5kN minimum breaking force while staying easy to handle through sheaves and drums.
The 7x19 construction is built around a wire core, so it holds its shape under load better than a fibre core rope. Grade 2070 wire, right hand ordinary lay, with a galvanised finish and dry lube for outdoor and coastal exposure. Approximate mass is 24.4kg per 100m, so weight is manageable on site. Check for broken wires, flattening and corrosion before each use and retire the rope if you find damage.
Common questions
- what is the breaking strength of 8mm 7x19 wire rope
- The Beaver G2070 8mm 7x19 rope has a minimum breaking force of 43.5kN. That is a breaking figure, not a working load limit, so apply the correct design factor for your application.
- is 7x19 wire rope more flexible than 7x7
- Yes. The 7x19 construction uses more, finer wires per strand, which makes it more flexible and better suited to running over sheaves and drums than coarser constructions.
- does galvanised wire rope rust
- The galvanised finish plus the dry lube gives good resistance in outdoor and marine air, but it is not rust proof. Inspect for corrosion and broken wires regularly and retire damaged rope.
Full specifications
| Product code | Wire Diameter | Construction | Grade | Finish | Core | Lay | MBF | Approx Mass |
|---|---|---|---|---|---|---|---|---|
| 712403 | 3.2mm | 7x19 | 2070 | Galvanised | Wire | RHOL | 7.1kN | 4.4kg/100m |
| 712404 | 4mm | 7x19 | 2070 | Galvanised | Wire | RHOL | 11.2kN | 6.22kg/100m |
| 712405 | 5mm | 7x19 | 2070 | Galvanised | Wire | RHOL | 17.2kN | 8.6kg/100m |
| 712406 | 6mm | 7x19 | 2070 | Galvanised | Wire | RHOL | 25kN | 12.4kg/100m |
| 712408 | 8mm | 7x19 | 2070 | Galvanised | Wire | RHOL | 43.5kN | 24.4kg/100m |
| 712410 | 10mm | 7x19 | 2070 | Galvanised | Wire | RHOL | 64.4kN | 46.1kg/100m |
Questions about this equipment? Send us a message and we’ll check it against the job.
