| Lay | RHOL |
| MBF | 18.8kN |
| Core | Fibre |
| Grade | 1570 |
| Finish | Galvanised |
| Diameter | 6mm |
| Approx Mass | 12.4kg/100m |
| Construction | 6x7 |
The Beaver G1570 Galvanised Wire Rope with a Fibre Core 6x7 in 6mm is a light, flexible rope for general fabrication, fencing, guying and utility work around the yard or site. The 6x7 construction gives you seven wires per strand over a dry lube fibre core, so it stays supple without being floppy. Minimum breaking force is 18.8kN, and the grade 1570 wire carries a galvanised finish to slow down surface rust in the weather.
At 6mm it is the mid range size in the G1570 fibre core family, and it weighs roughly 12.4kg per 100m, so it is easy to handle and run out by hand. The lay is right hand ordinary. Fibre core rope like this suits static and light duty jobs rather than heavy lifting, so match it to the task and keep an eye on broken wires, kinks and flattened sections.
| Product code | Diameter | Construction | Grade | Finish | Core | Lay | MBF | Approx Mass |
|---|---|---|---|---|---|---|---|---|
| 707302 | 2mm | 6x7 | 1570 | Galvanised | Fibre | RHOL | 2.1kN | 1.4kg/100m |
| 707302A | 2.5mm | 6x7 | 1570 | Galvanised | Fibre | RHOL | 3.2kN | 2.65kg/100m |
| 707303 | 3mm | 6x7 | 1570 | Galvanised | Fibre | RHOL | 4.7kN | 3.22kg/100m |
| 707304 | 4mm | 6x7 | 1570 | Galvanised | Fibre | RHOL | 8.4kN | 5.5kg/100m |
| 707305 | 5mm | 6x7 | 1570 | Galvanised | Fibre | RHOL | 13.1kN | 8.6kg/100m |
| 707306 | 6mm | 6x7 | 1570 | Galvanised | Fibre | RHOL | 18.8kN | 12.4kg/100m |
