Beaver G1570 Galvanised Wire Rope with a Fibre Core 6x7 3mm
707303per Each
$0.31 inc GSTTrade $0.28, save $0.03Trade accounts save 10%. Apply with your ABN
| Lay | RHOL |
| MBF | 4.7kN |
| Core | Fibre |
| Grade | 1570 |
| Finish | Galvanised |
| Diameter | 3mm |
| Approx Mass | 3.22kg/100m |
| Construction | 6x7 |
About this product
The Beaver G1570 Galvanised Wire Rope with a Fibre Core 6x7 in 3mm is a light gauge rope for guying, tie-backs, fencing runs and general tie-off work where flexibility matters more than raw strength. At 3mm it is the smallest diameter in the range, with a minimum breaking force of 4.7kN and an approximate mass of 3.22kg/100m, so it is easy to handle and pull through tight runs by hand.
The 6x7 construction runs seven wires in each of six strands around a dry lubed fibre core, giving the rope a bit of give without going soft. Grade 1570 wire with a galvanised finish holds up to damp and outdoor exposure better than bright rope. Lay is right hand ordinary. Check for broken wires, kinks and flattening before each use, and step up a diameter if you need more breaking force.
Common questions
- what is the breaking strain of 3mm 6x7 wire rope
- This 3mm Beaver G1570 rope has a minimum breaking force of 4.7kN. That is a breaking figure, not a working load limit, so apply your own design factor.
- is beaver 3mm wire rope galvanised
- Yes, it has a galvanised finish over grade 1570 wire, which gives it better resistance to moisture and outdoor conditions than bright rope.
- fibre core vs steel core wire rope which is better
- A fibre core like this 6x7 rope makes it more flexible and easier to handle at small diameters. A steel core rope is stiffer and stronger for the same size.
Full specifications
| Product code | Diameter | Construction | Grade | Finish | Core | Lay | MBF | Approx Mass |
|---|---|---|---|---|---|---|---|---|
| 707302 | 2mm | 6x7 | 1570 | Galvanised | Fibre | RHOL | 2.1kN | 1.4kg/100m |
| 707302A | 2.5mm | 6x7 | 1570 | Galvanised | Fibre | RHOL | 3.2kN | 2.65kg/100m |
| 707303 | 3mm | 6x7 | 1570 | Galvanised | Fibre | RHOL | 4.7kN | 3.22kg/100m |
| 707304 | 4mm | 6x7 | 1570 | Galvanised | Fibre | RHOL | 8.4kN | 5.5kg/100m |
| 707305 | 5mm | 6x7 | 1570 | Galvanised | Fibre | RHOL | 13.1kN | 8.6kg/100m |
| 707306 | 6mm | 6x7 | 1570 | Galvanised | Fibre | RHOL | 18.8kN | 12.4kg/100m |
Questions about this equipment? Send us a message and we’ll check it against the job.
