Beaver G1570 PVC Coated Galvanised Wire Rope With a Fibre Core - 6x19 (Blue) 5mm x 7mm
706050per Each
$1.34 inc GSTTrade $1.21, save $0.13Trade accounts save 10%. Apply with your ABN
| Lay | RHOL |
| MBF | 12.06kN |
| Core | Fibre |
| Grade | 1570 |
| Finish | Galvanised |
| Approx Mass | 8.6kg/100m |
| Construction | 6x19 |
| Wire Diameter | 5mm |
| PVC Outside Diameter | 7mm |
About this product
The Beaver G1570 PVC Coated Galvanised Wire Rope is a flexible 6x19 fibre core rope with a blue PVC jacket, used where a light, hand friendly rope is needed for barriers, guides, lanyards and general tie back work. This is the smallest size in the range, with a 5mm wire diameter sitting under a 7mm PVC outside diameter, so it suits tighter sheaves, small thimbles and jobs where bulk gets in the way.
Grade 1570 wire with a galvanised finish handles the corrosion side of things, and the PVC coat keeps the strands covered so hands and paintwork stay clean. Minimum breaking force is 12.06kN, right hand ordinary lay, with an approximate mass of 8.6kg/100m. The fibre core keeps it supple rather than stiff. Cut ends should be seized or terminated properly, and the coating checked for splits where water can get in.
Common questions
- what is the breaking strength of 5mm beaver pvc coated wire rope
- The minimum breaking force is 12.06kN. It is not a rated working load, so apply your own design factor for the application.
- what is the outside diameter of 5mm pvc coated wire rope
- The steel wire rope is 5mm and the blue PVC coating takes the outside diameter to 7mm. Size your thimbles, ferrules and sheaves to suit.
- is pvc coated galvanised wire rope good for outdoor use
- Yes, the galvanised finish plus the blue PVC jacket both help with corrosion outdoors. Keep an eye on the coating and reject rope where splits let water reach the strands.
Full specifications
| Product code | Wire Diameter | PVC Outside Diameter | Construction | Grade | Finish | Core | Lay | MBF | Approx Mass |
|---|---|---|---|---|---|---|---|---|---|
| 706030 | 3mm | 5mm | 6x19 | 1570 | Galvanised | Fibre | RHOL | 4.34kN | 3.16kg/100m |
| 706030A | 3.5mm | 5.5mm | 6x19 | 1570 | Galvanised | Fibre | RHOL | 5.92kN | 4.2kg/100m |
| 706040 | 4mm | 6mm | 6x19 | 1570 | Galvanised | Fibre | RHOL | 7.72kN | 5.5kg/100m |
| 706050 | 5mm | 7mm | 6x19 | 1570 | Galvanised | Fibre | RHOL | 12.06kN | 8.6kg/100m |
| 706060 | 6mm | 8mm | 6x19 | 1570 | Galvanised | Fibre | RHOL | 17.39kN | 12.4kg/100m |
| 706080 | 8mm | 10mm | 6x19 | 1570 | Galvanised | Fibre | RHOL | 30.9kN | 22.1kg/100m |
| 706100 | 10mm | 12mm | 6x19 | 1570 | Galvanised | Fibre | RHOL | 48.2kN | 34.6kg/100m |
Questions about this equipment? Send us a message and we’ll check it against the job.
