| Lay | RHOL |
| MBF | 20.5kN |
| UOM | Metre |
| Grade | 304 |
| Finish | Stainless Steel |
| Diameter | 6mm |
| Construction | 7x19 |
| Wire Diameter | 6mm |
| Metre Per Reel | 305m |
| Approx Mass Kg/100m | 14.21 |
Beaver G304 Stainless Steel Wire Rope in 7x19 construction is a flexible stainless rope for corrosion-prone rigging work, and this 6mm size carries a minimum breaking force of 20.5kN on a 305m reel length. The 7x19 make-up means plenty of strands doing the work, so it bends and handles better than stiffer stainless constructions of the same diameter. Lay is right hand ordinary, and mass runs around 14.21kg per 100m.
Grade 304 stainless holds up well against corrosion, which makes it a sensible pick for marine work, waste handling and outdoor jobs where galvanised rope would start showing rust. It does have limits in harsher chemical environments, so step up a grade if conditions are severe. The 6mm diameter suits balustrading, light lifting tackle and general fit-out where appearance matters as much as strength.
| Product Code | Diameter | Construction | Grade | Finish | Lay | MBF | Approx Mass Kg/100m | UOM | Metre Per Reel |
|---|---|---|---|---|---|---|---|---|---|
| 703016 | 1.6mm | 7x19 | 304 | Stainless Steel | RHOL | 1.85kN | 1.1 | Metre | 305 |
| 703020 | 2mm | 7x19 | 304 | Stainless Steel | RHOL | 2.89kN | 1.63 | Metre | 305 |
| 703025 | 2.5mm | 7x19 | 304 | Stainless Steel | RHOL | 4.43kN | 2.51 | Metre | 305 |
| 703030 | 3.2mm | 7x19 | 304 | Stainless Steel | RHOL | 7.82kN | 4.01 | Metre | 305 |
| 703040 | 4mm | 7x19 | 304 | Stainless Steel | RHOL | 10.67kN | 6.27 | Metre | 305 |
| 703040C | 4mm | 7x19 | 304 | Stainless Steel | RHOL | 10.67kN | 6.27 | Metre | 1000 |
| 703050 | 5mm | 7x19 | 304 | Stainless Steel | RHOL | 17.84kN | 9.81 | Metre | 305 |
| 703060 | 6mm | 7x19 | 304 | Stainless Steel | RHOL | 20.5kN | 14.21 | Metre | 305 |
| 703080 | 8mm | 7x19 | 304 | Stainless Steel | RHOL | 40kN | 25.03 | Metre | 305 |
