| Lay | RHOL |
| MBF | 10.67kN |
| UOM | Metre |
| Grade | 304 |
| Finish | Stainless Steel |
| Diameter | 4mm |
| Construction | 7x19 |
| Wire Diameter | 4mm |
| Metre Per Reel | 1000m |
| Approx Mass Kg/100m | 6.27 |
Beaver G304 Stainless Steel Wire Rope in 7x19, 4mm is a flexible stainless rope for corrosion-prone rigging and cable runs. The 4mm diameter sits in the lighter end of the range, with a minimum breaking force of 10.67kN and an approximate mass of 6.27kg per 100m, so it stays easy to handle and run out over long distances. Lay is right hand ordinary. The 1000m reel suits jobs where you are cutting plenty of shorter lengths.
The 7x19 construction uses 133 wires, which gives it more flex than a compact strand rope and makes it a better fit where the rope bends over sheaves or pulleys. Grade 304 is the standard stainless grade, with good resistance to corrosion in marine, waste management and outdoor work, though it has limits in harsher corrosive conditions. Common uses include balustrading and exposed architectural fitouts.
| Product Code | Diameter | Construction | Grade | Finish | Lay | MBF | Approx Mass Kg/100m | UOM | Metre Per Reel |
|---|---|---|---|---|---|---|---|---|---|
| 703016 | 1.6mm | 7x19 | 304 | Stainless Steel | RHOL | 1.85kN | 1.1 | Metre | 305 |
| 703020 | 2mm | 7x19 | 304 | Stainless Steel | RHOL | 2.89kN | 1.63 | Metre | 305 |
| 703025 | 2.5mm | 7x19 | 304 | Stainless Steel | RHOL | 4.43kN | 2.51 | Metre | 305 |
| 703030 | 3.2mm | 7x19 | 304 | Stainless Steel | RHOL | 7.82kN | 4.01 | Metre | 305 |
| 703040 | 4mm | 7x19 | 304 | Stainless Steel | RHOL | 10.67kN | 6.27 | Metre | 305 |
| 703040C | 4mm | 7x19 | 304 | Stainless Steel | RHOL | 10.67kN | 6.27 | Metre | 1000 |
| 703050 | 5mm | 7x19 | 304 | Stainless Steel | RHOL | 17.84kN | 9.81 | Metre | 305 |
| 703060 | 6mm | 7x19 | 304 | Stainless Steel | RHOL | 20.5kN | 14.21 | Metre | 305 |
| 703080 | 8mm | 7x19 | 304 | Stainless Steel | RHOL | 40kN | 25.03 | Metre | 305 |
Questions about this equipment? Send us a message and we’ll check it against the job.
