Beaver G304 Stainless Steel Wire Rope - 7X19 3.2mm x 305m
703030per Each
$1.27 inc GSTTrade $1.14, save $0.13Trade accounts save 10%. Apply with your ABN
| Lay | RHOL |
| MBF | 7.82kN |
| UOM | Metre |
| Grade | 304 |
| Finish | Stainless Steel |
| Diameter | 3.2mm |
| Construction | 7x19 |
| Wire Diameter | 3.2mm |
| Metre Per Reel | 305m |
| Approx Mass Kg/100m | 4.01 |
About this product
The Beaver G304 Stainless Steel Wire Rope in 7x19 construction is a flexible stainless rope for marine, outdoor and wash-down work where plain steel rusts out. At 3.2mm diameter it sits at the lighter end of the range, with a minimum breaking force of 7.82kN and an approximate mass of 4.01kg per 100m, so it handles easily while still carrying useful load.
Grade 304 stainless gives good corrosion resistance, though it has limits in the harshest environments. Lay is right hand ordinary. The 7x19 make-up uses more, finer wires than a 1x19 rope, so it bends and runs better rather than staying dead straight. Common jobs include balustrading, waste and water handling, and general outdoor rigging where a small, neat rope is wanted.
Common questions
- what is the breaking strength of 3.2mm 7x19 stainless wire rope
- This size has a minimum breaking force of 7.82kN. It is a breaking figure, not a working load limit, so apply your own design factor.
- is grade 304 stainless steel ok for marine use
- Grade 304 is a standard grade with good corrosion resistance and is widely used in marine and waste applications. It does have limitations in more heavily corrosive environments.
- 7x19 vs 1x19 stainless wire rope, what's the difference
- 1x19 is very stiff and suited to straight line rigging like mast stays and guy ropes. The 7x19 construction here uses finer wires in seven strands, making it more flexible for ropes that need to bend.
- how much does 3.2mm stainless wire rope weigh
- Approximately 4.01kg per 100m, so it is light to handle and pull through fittings.
Full specifications
| Product Code | Diameter | Construction | Grade | Finish | Lay | MBF | Approx Mass Kg/100m | UOM | Metre Per Reel |
|---|---|---|---|---|---|---|---|---|---|
| 703016 | 1.6mm | 7x19 | 304 | Stainless Steel | RHOL | 1.85kN | 1.1 | Metre | 305 |
| 703020 | 2mm | 7x19 | 304 | Stainless Steel | RHOL | 2.89kN | 1.63 | Metre | 305 |
| 703025 | 2.5mm | 7x19 | 304 | Stainless Steel | RHOL | 4.43kN | 2.51 | Metre | 305 |
| 703030 | 3.2mm | 7x19 | 304 | Stainless Steel | RHOL | 7.82kN | 4.01 | Metre | 305 |
| 703040 | 4mm | 7x19 | 304 | Stainless Steel | RHOL | 10.67kN | 6.27 | Metre | 305 |
| 703040C | 4mm | 7x19 | 304 | Stainless Steel | RHOL | 10.67kN | 6.27 | Metre | 1000 |
| 703050 | 5mm | 7x19 | 304 | Stainless Steel | RHOL | 17.84kN | 9.81 | Metre | 305 |
| 703060 | 6mm | 7x19 | 304 | Stainless Steel | RHOL | 20.5kN | 14.21 | Metre | 305 |
| 703080 | 8mm | 7x19 | 304 | Stainless Steel | RHOL | 40kN | 25.03 | Metre | 305 |
Questions about this equipment? Send us a message and we’ll check it against the job.
