Beaver G316 Stainless Steel Eye Nut 10mm
612510per Each
$4.10 inc GSTTrade $3.69, save $0.41Trade accounts save 10%. Apply with your ABN
| A | 7mm |
| B | 48.9mm |
| C | 25.8mm |
| Grade | 316 |
| Weight | 0.05kg |
| Thread Size | 10mm |
About this product
The Beaver G316 Stainless Steel Eye Nut 10mm is a threaded stainless fitting that gives you a fixed attachment point on a 10mm thread, for tie-down and general fastening work rather than lifting. The 10mm thread sits in the middle of the range, so it suits jobs where a smaller eye nut would be light on and a larger one will not thread up. Body dimensions run 7mm at A, 48.9mm at B and 25.8mm at C, with a weight of 0.05kg.
It is made from Grade 316 stainless, also called marine grade, which handles salt water and other harsh corrosive conditions far better than plain steel. That makes it a sensible pick for boats, coastal sheds and anywhere the air carries salt. It is also used in food and pharmaceutical processing. This fitting is not to be used for lifting.
Common questions
- can you use a Beaver G316 eye nut for lifting
- No. This fitting is not to be used for lifting, so keep it to non-lifting attachment and tie-down work.
- what does grade 316 stainless mean on an eye nut
- Grade 316 is marine grade stainless with high corrosion resistance, made for harsher corrosive conditions like salt water.
- what thread size is the 10mm Beaver stainless eye nut
- It has a 10mm thread size, with A at 7mm, B at 48.9mm and C at 25.8mm, and it weighs 0.05kg.
Full specifications
| Product Code | Thread Size | A | B | C | Grade | Weight |
|---|---|---|---|---|---|---|
| 612506 | 6mm | 4.7mm | 31.3mm | 16.3mm | 316 | 0.015kg |
| 612508 | 8mm | 5mm | 38.7mm | 21mm | 316 | 0.024kg |
| 612510 | 10mm | 7mm | 48.9mm | 25.8mm | 316 | 0.05kg |
| 612512 | 12mm | 9.6mm | 59.7mm | 30.3mm | 316 | 0.08kg |
| 612516 | 16mm | 12mm | 70.3mm | 35.3mm | 316 | 0.18kg |
