Beaver G316 Stainless Steel Eye Nut 8mm
612508per Each
$7.49 inc GSTTrade $6.74, save $0.75Trade accounts save 10%. Apply with your ABN
| A | 5mm |
| B | 38.7mm |
| C | 21mm |
| Grade | 316 |
| Weight | 0.024kg |
| Thread Size | 8mm |
About this product
The Beaver G316 Stainless Steel Eye Nut 8mm gives you a threaded anchor point for rope, wire or shackles where corrosion is the main enemy. It threads onto an 8mm bolt or stud, with a 38.7mm overall height, a 21mm eye and a 5mm section at the ring. At 0.024kg it is a small fitting, so it suits light tie backs, guys and general fit out rather than anything structural.
Grade 316 stainless, also called marine grade, is what makes this one worth the money. It holds up in salt water and other harsher corrosive conditions, which is why you see it on boats and anywhere close to the coast. The same grade also suits food and pharmaceutical processing work. One thing to be clear on, this fitting is not to be used for lifting.
Common questions
- can you use a stainless eye nut for lifting
- No. This fitting is not to be used for lifting, so keep it to tie back, restraint and general fit out work.
- what size thread does the beaver 8mm eye nut take
- It has an 8mm thread, so it suits an 8mm bolt or stud. Overall height is 38.7mm with a 21mm eye.
- is grade 316 stainless steel ok for salt water
- Yes, Grade 316 is marine grade stainless with high corrosion resistance and is intended for harsher corrosive applications like salt water and coastal environments.
- what is the difference between grade 316 and grade 304 eye nuts
- This one is Grade 316, the marine grade, which handles harsher corrosive conditions such as salt water better than lower grades.
Full specifications
| Product Code | Thread Size | A | B | C | Grade | Weight |
|---|---|---|---|---|---|---|
| 612506 | 6mm | 4.7mm | 31.3mm | 16.3mm | 316 | 0.015kg |
| 612508 | 8mm | 5mm | 38.7mm | 21mm | 316 | 0.024kg |
| 612510 | 10mm | 7mm | 48.9mm | 25.8mm | 316 | 0.05kg |
| 612512 | 12mm | 9.6mm | 59.7mm | 30.3mm | 316 | 0.08kg |
| 612516 | 16mm | 12mm | 70.3mm | 35.3mm | 316 | 0.18kg |
