Beaver G316 Stainless Steel Eye Nut 6mm
612506per Each
$2.58 inc GSTTrade $2.32, save $0.26Trade accounts save 10%. Apply with your ABN
| A | 4.7mm |
| B | 31.3mm |
| C | 16.3mm |
| Grade | 316 |
| Weight | 0.015kg |
| Thread Size | 6mm |
About this product
The Beaver G316 Stainless Steel Eye Nut 6mm is a marine grade stainless fitting that gives you a fixed eye anchor point wherever a 6mm thread is available. It is the smallest thread in the range, so it suits light tie-off and attachment work rather than heavy fitout. Overall height runs 31.3mm, with a 16.3mm eye dimension and 4.7mm section, and the whole thing weighs just 0.015kg.
Grade 316 stainless, also called marine grade, holds up well against corrosion in salt water and coastal air. That makes it a sensible pick for boats, jetty hardware, wash-down areas and food or pharmaceutical processing gear. One thing to be clear on. This eye nut is not rated for lifting and should not be used in any lifting application. Keep it for static attachment and restraint duties.
Common questions
- can you lift with a Beaver G316 stainless eye nut
- No. This fitting is not to be used for lifting, so keep it to non-lifting attachment and tie-off work.
- what is grade 316 stainless steel good for
- Grade 316 is marine grade stainless with high corrosion resistance, so it handles salt water, coastal air and harsher corrosive settings, along with food and pharmaceutical processing.
- what thread does the 6mm Beaver eye nut take
- It has a 6mm thread size, the smallest in the Beaver G316 eye nut range, with an overall height of 31.3mm.
Full specifications
| Product Code | Thread Size | A | B | C | Grade | Weight |
|---|---|---|---|---|---|---|
| 612506 | 6mm | 4.7mm | 31.3mm | 16.3mm | 316 | 0.015kg |
| 612508 | 8mm | 5mm | 38.7mm | 21mm | 316 | 0.024kg |
| 612510 | 10mm | 7mm | 48.9mm | 25.8mm | 316 | 0.05kg |
| 612512 | 12mm | 9.6mm | 59.7mm | 30.3mm | 316 | 0.08kg |
| 612516 | 16mm | 12mm | 70.3mm | 35.3mm | 316 | 0.18kg |
