| A | 60.7mm |
| B | 25.6mm |
| C | M10 |
| Grade | 316 |
| Weight | 0.05kg |
| Thread Size | 10mm |
The Beaver G316 Stainless Steel Eye Bolt 10mm is a marine grade anchor point for tie-downs, guy lines and general fixing work where rust is the enemy. This size runs an M10 thread with a 60.7mm overall length and a 25.6mm eye, so it suits mid-weight rope, shackle or turnbuckle connections without the bulk of the larger sizes in the range. At 0.05kg it is light enough to use in numbers across a deck or frame.
Grade 316 stainless, often called marine grade, holds up in salt water and other harsh corrosive conditions far better than lesser grades. That makes it a sensible pick for boats, coastal structures, and food or pharmaceutical processing gear where washdowns are constant. One thing to be clear on, this fitting is not to be used for lifting. Keep it to static restraint and fixing duties.
| Product Code | Thread Size | A | B | C | Grade | Weight |
|---|---|---|---|---|---|---|
| 612406 | 6mm | 37.4mm | 16.8mm | M6 | 316 | 0.01kg |
| 612408 | 8mm | 47mm | 20.6mm | M8 | 316 | 0.02kg |
| 612410 | 10mm | 60.7mm | 25.6mm | M10 | 316 | 0.05kg |
| 612412 | 12mm | 72.3mm | 29.7mm | M12 | 316 | 0.1kg |
| 612416 | 16mm | 86mm | 35mm | M16 | 316 | 0.15kg |
