Beaver G316 Stainless Steel Eye Bolt 8mm
612408per Each
$6.83 inc GSTTrade $6.15, save $0.68Trade accounts save 10%. Apply with your ABN
| A | 47mm |
| B | 20.6mm |
| C | M8 |
| Grade | 316 |
| Weight | 0.02kg |
| Thread Size | 8mm |
About this product
The Beaver G316 Stainless Steel Eye Bolt 8mm is a marine grade anchor point for tie-downs, rope runs and light fittings where rust is the enemy. This is the M8 thread version, 47mm overall with a 20.6mm eye, so it suits the smaller holes and lighter hardware in the range. At 0.02kg it adds next to nothing to the job.
Grade 316 stainless, also known as marine grade, holds up in salt water and coastal air far better than plain steel or lower stainless grades. That makes it a sensible pick for boats, jetty hardware, wash-down areas and food or pharmaceutical processing gear. One thing to be clear on, this fitting is not to be used for lifting. Keep it for restraint and general fastening work, and use rated lifting hardware where loads are being picked.
Common questions
- Can you use the Beaver G316 eye bolt for lifting?
- No. This fitting is not to be used for lifting, so keep it for tie-down, restraint and general fastening work.
- What size thread is the 8mm Beaver stainless eye bolt?
- It has an M8 thread. Overall length is 47mm and the eye measures 20.6mm.
- Is 316 stainless better than 304 for salt water?
- Yes. Grade 316 is the marine grade and has higher corrosion resistance, so it handles salt water and coastal conditions better.
Full specifications
| Product Code | Thread Size | A | B | C | Grade | Weight |
|---|---|---|---|---|---|---|
| 612406 | 6mm | 37.4mm | 16.8mm | M6 | 316 | 0.01kg |
| 612408 | 8mm | 47mm | 20.6mm | M8 | 316 | 0.02kg |
| 612410 | 10mm | 60.7mm | 25.6mm | M10 | 316 | 0.05kg |
| 612412 | 12mm | 72.3mm | 29.7mm | M12 | 316 | 0.1kg |
| 612416 | 16mm | 86mm | 35mm | M16 | 316 | 0.15kg |
