| A | 37.4mm |
| B | 16.8mm |
| C | M6 |
| Grade | 316 |
| Weight | 0.01kg |
| Thread Size | 6mm |
The Beaver G316 Stainless Steel Eye Bolt 6mm is a small M6 threaded eye bolt for making a fixed attachment point where corrosion is the main worry. It is the smallest and lightest option in the range at 0.01kg, with a 37.4mm overall length and a 16.8mm eye. Handy where space is tight and the load is light, such as light tie-offs, guide lines and fit-out work on boats.
Grade 316 stainless, often called marine grade, holds up well against salt water and other harsh corrosive conditions. That makes it a sensible pick for coastal jobs, wash-down areas, and food or pharmaceutical processing where hygiene and rust resistance matter. One thing to be clear on, this fitting is not to be used for lifting. Keep it for restraint and attachment duties and use rated lifting gear when there is a load overhead.
| Product Code | Thread Size | A | B | C | Grade | Weight |
|---|---|---|---|---|---|---|
| 612406 | 6mm | 37.4mm | 16.8mm | M6 | 316 | 0.01kg |
| 612408 | 8mm | 47mm | 20.6mm | M8 | 316 | 0.02kg |
| 612410 | 10mm | 60.7mm | 25.6mm | M10 | 316 | 0.05kg |
| 612412 | 12mm | 72.3mm | 29.7mm | M12 | 316 | 0.1kg |
| 612416 | 16mm | 86mm | 35mm | M16 | 316 | 0.15kg |
Questions about this equipment? Send us a message and we’ll check it against the job.
