Beaver G316 Stainless Steel Jaw and Jaw Bottle Screw with Lock Nuts 10mm
601510per Each
$66.42 inc GSTTrade $59.78, save $6.64Trade accounts save 10%. Apply with your ABN
| A | 212mm |
| B | 121mm |
| C | 15mm |
| D | M10mm |
| Grade | 316 |
| Weight | 0.28kg |
| Thread Size | 10mm |
About this product
The Beaver G316 Stainless Steel Jaw and Jaw Bottle Screw with Lock Nuts 10mm is a tensioner for wire rope and rod assemblies where you need to pull the slack out and hold it there. This is the M10 thread size, 212mm overall with a 121mm body and 15mm jaw opening, weighing 0.28kg. Jaw fittings at both ends take removable pins, so you can pull it out of the assembly and adjust without dismantling the whole run.
Made from marine grade 316 stainless with an electro polished finish, it handles salt spray and other corrosive conditions, and the finish suits food and pharmaceutical processing work. The lock nuts hold your setting once the tension is right. Worth noting, this is a fastening and tensioning item, not for lifting applications.
Common questions
- can you use a bottle screw for lifting
- No. This bottle screw is not to be used for lifting applications, it is made for fastening and tensioning only.
- what does the 10mm mean on a bottle screw
- It refers to the thread size, M10 in this case. The fitting measures 212mm overall with a 121mm body and a 15mm jaw opening.
- is 316 stainless ok in salt water
- Yes, grade 316 is marine grade stainless with high corrosion resistance, and this one has an electro polished surface finish for harsh salt water environments.
Full specifications
| Product Code | Thread Size | A | B | C | D | Grade | Weight |
|---|---|---|---|---|---|---|---|
| 601505 | 5mm | 138mm | 81mm | 10.3mm | M5mm | 316 | 0.04kg |
| 601506 | 6mm | 153mm | 92mm | 10.3mm | M6mm | 316 | 0.07kg |
| 601508 | 8mm | 188mm | 112mm | 11.2mm | M8mm | 316 | 0.15kg |
| 601510 | 10mm | 212mm | 121mm | 15mm | M10mm | 316 | 0.28kg |
| 601512 | 12mm | 266mm | 150mm | 17.5mm | M12mm | 316 | 0.49kg |
