Beaver G316 Stainless Steel Jaw and Jaw Bottle Screw with Lock Nuts 5mm
601505per Each
$15.14 inc GSTTrade $13.63, save $1.51Trade accounts save 10%. Apply with your ABN
| A | 138mm |
| B | 81mm |
| C | 10.3mm |
| D | M5mm |
| Grade | 316 |
| Weight | 0.04kg |
| Thread Size | 5mm |
About this product
The Beaver G316 Stainless Steel Jaw and Jaw Bottle Screw with Lock Nuts 5mm is the smallest thread in the range, suited to light wire rope and cable tensioning where space is tight. The M5 thread runs 138mm closed with an 81mm take-up body and a 10.3mm jaw width, and the whole fitting weighs just 0.04kg. Jaws at both ends take removable pins, so you can pull it out of a run and reset the tension without cutting anything loose.
Made from marine grade 316 stainless with an electro polished finish, it stands up to salt water and other corrosive conditions, and it is clean enough for food and pharmaceutical processing work. The lock nuts hold your setting once the tension is right. Worth noting, this is a tensioning fitting only and is not to be used for lifting applications.
Common questions
- can you use a bottle screw for lifting
- No. Beaver states these bottle screws are not to be used for lifting applications, they are for tensioning and fastening only.
- what is the length of the 5mm beaver bottle screw
- It measures 138mm overall with an 81mm adjustment body, and the jaw width is 10.3mm.
- is 316 stainless ok in salt water
- Yes, grade 316 is marine grade and has high corrosion resistance, so it handles salt water and other harsh corrosive environments. This one also has an electro polished surface finish.
Full specifications
| Product Code | Thread Size | A | B | C | D | Grade | Weight |
|---|---|---|---|---|---|---|---|
| 601505 | 5mm | 138mm | 81mm | 10.3mm | M5mm | 316 | 0.04kg |
| 601506 | 6mm | 153mm | 92mm | 10.3mm | M6mm | 316 | 0.07kg |
| 601508 | 8mm | 188mm | 112mm | 11.2mm | M8mm | 316 | 0.15kg |
| 601510 | 10mm | 212mm | 121mm | 15mm | M10mm | 316 | 0.28kg |
| 601512 | 12mm | 266mm | 150mm | 17.5mm | M12mm | 316 | 0.49kg |
