can you use a stainless turnbuckle for lifting

No. These Beaver G316 turnbuckles are not to be used for lifting applications. They are for tensioning only.

what thread size is the 5mm beaver turnbuckle

It has an M5 thread, with a 127.5mm overall length and a 71mm body take-up.

is 316 stainless ok near saltwater

Yes, grade 316 is marine grade stainless with high corrosion resistance, so it suits harsh corrosive environments and coastal work.

Beaver G316 Stainless Steel Hook and Eye Turnbuckles with Lock Nuts 5mm

Name: Beaver G316 Stainless Steel Hook and Eye Turnbuckles with Lock Nuts 5mm
Brand: Beaver
SKU: 600405
Price: 7.89 AUD
Availability: InStock

600405per Each

Thread Size

$7.89 inc GSTTrade $7.10, save $0.79Trade accounts save 10%. Apply with your ABN

A	127.5mm
B	71mm
C	9.5mm
D	M5mm
E	10mm
Grade	316
Weight	0.05kg
Size (mm)	5mm
Thread Size	5mm

About this product

The Beaver G316 Stainless Steel Hook and Eye Turnbuckle with Lock Nuts in 5mm is the smallest thread size in the range, made for tensioning light wire, rope and stay lines. It runs an M5 thread with a 127.5mm overall length, a 71mm take-up body, a 9.5mm eye and a 10mm hook opening, and weighs 0.05kg. Grade 316 stainless throughout, so it handles salt air, wash-down areas and other corrosive spots without rusting out.

One end is threaded left hand, the other right hand. Turn the frame and both bolts draw in together, shortening the unit and pulling tension into whatever it is fitted to. Back the lock nuts up against the frame once you have the adjustment right and it stays put. This turnbuckle is not to be used for lifting applications.

Common questions

can you use a stainless turnbuckle for lifting: No. These Beaver G316 turnbuckles are not to be used for lifting applications. They are for tensioning only.
what thread size is the 5mm beaver turnbuckle: It has an M5 thread, with a 127.5mm overall length and a 71mm body take-up.
is 316 stainless ok near saltwater: Yes, grade 316 is marine grade stainless with high corrosion resistance, so it suits harsh corrosive environments and coastal work.

Full specifications

Product Code	Size (mm)	A	B	C	D	E	Grade	Weight
600404	4mm	110mm	61.5mm	9mm	M4mm	8mm	316	0.02kg
600405	5mm	127.5mm	71mm	9.5mm	M5mm	10mm	316	0.05kg
600406	6mm	163mm	90.5mm	9mm	M6mm	12mm	316	0.08kg
600408	8mm	212mm	122mm	10.3mm	M8mm	14mm	316	0.15kg
600410	9mm	259mm	151.5mm	12.5mm	M10mm	16mm	316	0.29kg
600412	12mm	321mm	201mm	14mm	M12mm	18mm	316	0.59kg
