Beaver 3S Industrial Manual Chain Blocks with Overload Protection (6m Standard Lift) 0.5t
508056per Each
$219.07 inc GSTTrade $197.16, save $21.91Trade accounts save 10%. Apply with your ABN
| A | 132mm |
| B | 148mm |
| C | 28mm |
| H | 345mm |
| Net Weight | 12.6kg |
| Colour Code | White |
| Standard Lift | 6m |
| Rated Capacity | 0.5t |
| Load Chain Diameter | 5mm x 15mm |
| No. Load Chain Falls | 1 |
| Effort on Lever to Lift Full Load | 240kg |
About this product
The Beaver 3S Industrial Manual Chain Block with Overload Protection is the 0.5t size in the range, the lightest option at 12.6kg net and colour coded white. It runs a single fall of 5mm x 15mm G80 calibrated load chain over a 6m standard lift, so it suits maintenance work on monorails, jibs and fixed installations where you want a hoist you can shift by hand without a second set of arms.
Housing is cast steel with a reinforced gear case and side covers, and a double pawl with double roller guide keeps the hand chain feeding cleanly into the wheel sprocket. Top and bottom hooks run on ball bearings and carry safety catches. Effort on the lever to lift full load is 240kg. Use it for vertical lifts only, since side loading can jam the load chain. Complies to AS/NZS 1418.2, with Grade 80 calibrated chain marked according to ISO 3077, and each block carries its own serial number tied to a test certificate.
Common questions
- what is the lift height on the beaver 3S 0.5t chain block
- Standard lift is 6m on a single fall of load chain. The rated capacity is 0.5t.
- can you side load a beaver 3S chain block
- No. These blocks are for vertical lifts only, as side loading or horizontal use can jam the load chain and damage the block.
- what chain does the beaver 3S 0.5t use
- It runs G80 calibrated load chain at 5mm x 15mm, marked according to ISO 3077, in a single fall.
Full specifications
| Product Code | Rated Capacity | Colour Code | Standard Lift | Effort on Lever to Lift Full Load | No. Load Chain Falls | Load Chain Diameter |
|---|---|---|---|---|---|---|
| 508056 | 0.5t | White | 6m | 240kg | 1 | 5mm x 15mm |
| 508106 | 1t | Violet | 6m | 250kg | 1 | 6mm x 18mm |
| 508206 | 2t | Green | 6m | 335kg | 1 | 8mm x 24mm |
| 508306 | 3t | Yellow | 6m | 335kg | 2 | 8mm x 24mm |
| 508506 | 5t | Red | 6m | 363kg | 2 | 9mm x 30mm |
| 508606 | 10t | Orange | 6m | 380kg | 4 | 9mm x 30mm |
| Product Code | Rated Capacity | A | B | C | H | Net Weight |
|---|---|---|---|---|---|---|
| 508056 | 0.5t | 132mm | 148mm | 28mm | 345mm | 12.6kg |
| 508106 | 1t | 151mm | 172mm | 32mm | 376mm | 14.8kg |
| 508206 | 2t | 175mm | 210mm | 36mm | 470mm | 23.6kg |
| 508306 | 3t | 176mm | 230mm | 46mm | 565mm | 37.2kg |
| 508506 | 5t | 189mm | 280mm | 46mm | 688mm | 54.5kg |
| 508606 | 10t | 189mm | 463mm | 57mm | 765mm | 104.9kg |
