Beaver 3S Manual Lever Blocks 1.6t
506160per Each
$283.68 inc GSTTrade $255.31, save $28.37Trade accounts save 10%. Apply with your ABN
| A | 172mm |
| B | 98mm |
| C | 160mm |
| D | 410mm |
| E | 35mm |
| H | 380mm |
| Net Weight | 11kg |
| Colour Code | Violet |
| Standard Lift | 1.5m |
| Rated Capacity | 1.6t |
| Load Chain Diameter | 8mm x 24mm |
| No. Load Chain Falls | 1 |
| Effort on Lever to Lift Full Load | 240N |
About this product
The Beaver 3S Manual Lever Block 1.6t is a hand operated lever hoist for lifting, pulling and tensioning loads up to 1.6 tonnes. This size runs a single fall of 8mm x 24mm Grade 80 load chain with a 1.5m standard lift, and it takes 240N of effort on the lever to move a full load. Violet colour coding marks the capacity at a glance on site, and at 11kg it is still a one hand carry between jobs.
Gears and mechanism sit inside an all steel shell, with the load chain calibrated and marked according to ISO 3077 and ISO 1834. Stainless ID plates and rivets cut the risk of sparking, which suits underground work. Body dimensions are 410mm closed height and 380mm across the handle. Every unit is operationally tested to rated capacity and supplied with a test certificate matching the stamped side plate. Complies to AS 1418.2.
Common questions
- what is the beaver 3s 1.6t lever block rated for
- It has a rated capacity of 1.6 tonnes on a single fall of load chain. Each unit is operationally tested to that rated capacity and comes with a test certificate.
- what size chain is in the 1.6t beaver lever block
- It uses 8mm x 24mm Grade 80 load chain, calibrated and marked according to ISO 3077 and ISO 1834.
- can you use a beaver 3s lever block underground
- Yes. The ID plates and rivets are stainless steel to avoid sparking, which makes it suited to underground mining work.
Full specifications
| Product Ccode | Rated Capacity | Colour Code | Standard Lift | Effort on Lever to Lift Full Load | No. Load Chain Fails | Load Chain Diameter |
|---|---|---|---|---|---|---|
| 506025 | 0.25t | Grey | 1.5m | 210N | 1 | 4mm |
| 506050 | 0.5t | Grey | 1.5M | 320N | 1 | 4mm |
| Product Code | Rated Capacity | A | B | C | D | E | H | Net Weight |
|---|---|---|---|---|---|---|---|---|
| 506025 | 0.25t | 87mm | 55.5mm | 68mm | 145mm | 21mm | 200mm | 1.5kg |
| 506050 | 0.5t | 100.5mm | 62.5mm | 81mm | 160mm | 24.5mm | 250mm | 2.5kg |
| Product code | Rated Capacity | Colour Code | Standard Lift | Effort on Lever to Lift Full Load | No. Load Chain Falls | Load Chain Diameter |
|---|---|---|---|---|---|---|
| 506080 | 0.8t | White | 1.5m | 140N | 1 | 6mm x 18mm |
| 506160 | 1.6t | Violet | 1.5m | 240N | 1 | 8mm x 24mm |
| 506320 | 3.2t | Yellow | 1.5m | 320N | 1 | 10mm x 30mm |
| 506630 | 6.3t | Brown | 1.5m | 340N | 2 | 10mm x 30mm |
| Product Code | Rated Capacity | A | B | C | D | E | H | Net Weight |
|---|---|---|---|---|---|---|---|---|
| 506080 | 0.8t | 148mm | 90mm | 136mm | 280mm | 30mm | 325mm | 7kg |
| 506160 | 1.6t | 172mm | 98mm | 160mm | 410mm | 35mm | 380mm | 11kg |
| 506320 | 3.2t | 200mm | 115mm | 180mm | 410mm | 40mm | 480mm | 21kg |
| 506630 | 6.3t | 200mm | 115mm | 235mm | 410mm | 50mm | 620mm | 31kg |
