Beaver G70 Gold Drag Chain Kit with Lug Link and Grab Hook 10mm
410010per Each
$141.39 inc GSTTrade $127.25, save $14.14Trade accounts save 10%. Apply with your ABN
| UOM | Each |
| LC (kg) | 6000kg |
| Chain Size | 10mm |
| Weight (kg) | 12.2 |
| Chain Size (mm) | 10 |
| Chain Length (m) | 5 |
| Chain Part Number | 145010 |
| Lug Link Part Number | 353010 |
| Grab Hook Part Number | 354010 |
About this product
The Beaver G70 Gold Drag Chain Kit with Lug Link and Grab Hook 10mm is a ready to go load restraint assembly for tying down machinery, steel and heavy plant on trucks and floats. This is the heaviest of the three sizes in the range, with a 6000kg lashing capacity on 5m of 10mm Grade 70 chain, so it suits the loads that smaller chain will not hold. The kit pairs chain part 145010 with lug link 353010 and grab hook 354010.
Chain and fittings are heat treated carbon steel with a zinc di-chromate gold finish, and the yellow plating makes the chain easy to pick out on a deck or in a toolbox from a distance. Everything is stamped Grade 70 with the lashing capacity and chain size, so a load inspector can read it without guesswork. Manufactured to AS/NZS 4344. Kit weight is 12.2kg.
Common questions
- what is the lashing capacity of 10mm g70 chain
- This kit is rated at 6000kg lashing capacity. The figure is stamped on the chain and fittings along with the Grade 70 marking and chain size.
- how long is the chain in the beaver drag chain kit
- The 10mm kit comes with 5m of Grade 70 chain, fitted with a lug link and a grab hook.
- why is g70 chain gold in colour
- The gold colour comes from a zinc di-chromate plating. It makes Grade 70 restraint chain easy to identify from a distance on a loaded truck.
Full specifications
| Product Code | Chain Size (mm) | Chain Length (m) | Chain Part Number | Grab Hook Part Number | Lug Link Part Number | LC (kg) | Weight (kg) | UOM |
|---|---|---|---|---|---|---|---|---|
| 410008 | 8 | 5 | 145008 | 354008 | 353008 | 3800kg | 8.03 | Each |
| 410010 | 10 | 5 | 145010 | 354010 | 353010 | 6000kg | 12.2 | Each |
| 410013 | 13 | 5 | 145013 | 354013 | 353013 | 9000kg | 20.78 | Each |
Questions about this equipment? Send us a message and we’ll check it against the job.
