Beaver Metric Shouldered Eye Nuts 24mm
359224per Each
$10.28 inc GSTTrade $9.25, save $1.03Trade accounts save 10%. Apply with your ABN
| E | 20mm |
| H | 90mm |
| W | 90mm |
| D1 | 50mm |
| D2 | 24mm |
| D3 | 20mm |
| D4 | 50mm |
| WLL | 1.8t |
| Finish | Zinc Dichromate |
| Weight | 0.72kg |
| Size (mm) | 24mm |
| Thread Size | 24mm |
| Transverse Load Tonne | 0.45 |
About this product
The Beaver Metric Shouldered Eye Nut 24mm is a threaded lifting point that screws onto a 24mm stud or bolt to give you a fixed eye for slings, shackles or hooks. This size carries a 1.8t working load limit in straight line pull, with a transverse load rating of 0.45t when the pull comes off at an angle. It is rated to DIN 582.
The shoulder seats flat against the load, which is what lets it handle side loading rather than axial pull only. Dimensions are 90mm high and 90mm wide, with a 50mm eye body and a 20mm eye section, and it weighs 0.72kg. The zinc dichromate finish gives it some corrosion resistance for general site and workshop use. Step up or down through the range if your thread size differs.
Common questions
- what is the WLL of a 24mm eye nut
- This 24mm Beaver eye nut is rated to a 1.8t working load limit for straight line lifting. Transverse loading drops the rating to 0.45t.
- can you side load a shouldered eye nut
- Yes, the shoulder is designed to bear against the load so it can take angled pull, but the rating falls to 0.45t transverse compared with 1.8t in line.
- what standard are beaver eye nuts made to
- This eyenut is rated to DIN 582. The finish is zinc dichromate.
Full specifications
| Product Code | Size (mm) | WLL | Transverse Load Tonne | Finish | Weight |
|---|---|---|---|---|---|
| 359208 | 8mm | 0.14t | 0.03 | Zinc Dichromate | 0.05kg |
| 359210 | 10mm | 0.23t | 0.06 | Zinc Dichromate | 0.09kg |
| 359212 | 12mm | 0.3t | 0.07 | Zinc Dichromate | 0.16kg |
| 359216 | 16mm | 0.7t | 0.17 | Zinc Dichromate | 0.24kg |
| 359220 | 20mm | 1.2t | 0.3 | Zinc Dichromate | 0.36kg |
| 359222 | 22mm | 1.5t | 0.37 | Zinc Dichromate | 0.58kg |
| 359224 | 24mm | 1.8t | 0.45 | Zinc Dichromate | 0.72kg |
| Product Code | Size (mm) | W | H | D1 | D2 | D3 | D4 | E |
|---|---|---|---|---|---|---|---|---|
| 359208 | 8mm | 36mm | 36mm | 20mm | 8mm | 8mm | 20mm | 8.5mm |
| 359210 | 10mm | 45mm | 45mm | 25mm | 10mm | 10mm | 25mm | 10mm |
| 359212 | 12mm | 54mm | 52mm | 30mm | 12mm | 12mm | 30mm | 11mm |
| 359216 | 16mm | 63mm | 61mm | 35mm | 16mm | 14mm | 35mm | 13mm |
| 359220 | 20mm | 72mm | 70mm | 40mm | 20mm | 16mm | 40mm | 16mm |
| 359222 | 22mm | 81mm | 80mm | 45mm | 22mm | 18mm | 45mm | 19.4mm |
| 359224 | 24mm | 90mm | 90mm | 50mm | 24mm | 20mm | 50mm | 20mm |
Questions about this equipment? Send us a message and we’ll check it against the job.
