Beaver Metric Shouldered Eye Nuts 22mm
359222per Each
$9.53 inc GSTTrade $8.58, save $0.95Trade accounts save 10%. Apply with your ABN
| E | 19.4mm |
| H | 80mm |
| W | 81mm |
| D1 | 45mm |
| D2 | 22mm |
| D3 | 18mm |
| D4 | 45mm |
| WLL | 1.5t |
| Finish | Zinc Dichromate |
| Weight | 0.58kg |
| Size (mm) | 22mm |
| Thread Size | 22mm |
| Transverse Load Tonne | 0.37 |
About this product
The Beaver Metric Shouldered Eye Nut 22mm gives you a threaded lifting point on machinery, dies and fabricated loads, ready to take a hook, shackle or sling. This is the 22mm thread size in the range, rated to a 1.5t working load limit in straight vertical lift, with a 0.37 tonne transverse load rating when the pull comes off the vertical. It is rated to DIN 582.
The body stands 80mm tall with an 81mm eye width and a 19.4mm eye section, so there is room for a decent shackle pin. The 45mm shoulder seats flat against the load, which is what keeps the nut from bending under angled pull. Zinc dichromate finish handles general site and workshop conditions. At 0.58kg it is easy to keep a few in the toolbox. Check the thread and eye for distortion before every lift.
Common questions
- what is the WLL of a 22mm eye nut
- The 22mm Beaver Metric Shouldered Eye Nut has a working load limit of 1.5t for a straight vertical lift. Transverse loading drops that to 0.37 tonne.
- beaver eye nut 22mm thread size and dimensions
- Thread size is 22mm, with an 80mm overall height, 81mm width, 19.4mm eye section and a 45mm shoulder diameter. Weight is 0.58kg.
- what standard are beaver metric eye nuts rated to
- This eyenut is rated to DIN 582. That is the only standard the supplier lists for it.
Full specifications
| Product Code | Size (mm) | WLL | Transverse Load Tonne | Finish | Weight |
|---|---|---|---|---|---|
| 359208 | 8mm | 0.14t | 0.03 | Zinc Dichromate | 0.05kg |
| 359210 | 10mm | 0.23t | 0.06 | Zinc Dichromate | 0.09kg |
| 359212 | 12mm | 0.3t | 0.07 | Zinc Dichromate | 0.16kg |
| 359216 | 16mm | 0.7t | 0.17 | Zinc Dichromate | 0.24kg |
| 359220 | 20mm | 1.2t | 0.3 | Zinc Dichromate | 0.36kg |
| 359222 | 22mm | 1.5t | 0.37 | Zinc Dichromate | 0.58kg |
| 359224 | 24mm | 1.8t | 0.45 | Zinc Dichromate | 0.72kg |
| Product Code | Size (mm) | W | H | D1 | D2 | D3 | D4 | E |
|---|---|---|---|---|---|---|---|---|
| 359208 | 8mm | 36mm | 36mm | 20mm | 8mm | 8mm | 20mm | 8.5mm |
| 359210 | 10mm | 45mm | 45mm | 25mm | 10mm | 10mm | 25mm | 10mm |
| 359212 | 12mm | 54mm | 52mm | 30mm | 12mm | 12mm | 30mm | 11mm |
| 359216 | 16mm | 63mm | 61mm | 35mm | 16mm | 14mm | 35mm | 13mm |
| 359220 | 20mm | 72mm | 70mm | 40mm | 20mm | 16mm | 40mm | 16mm |
| 359222 | 22mm | 81mm | 80mm | 45mm | 22mm | 18mm | 45mm | 19.4mm |
| 359224 | 24mm | 90mm | 90mm | 50mm | 24mm | 20mm | 50mm | 20mm |
