Beaver Metric Shouldered Eye Nuts 16mm
359216per Each
$3.81 inc GSTTrade $3.43, save $0.38Trade accounts save 10%. Apply with your ABN
| E | 13mm |
| H | 61mm |
| W | 63mm |
| D1 | 35mm |
| D2 | 16mm |
| D3 | 14mm |
| D4 | 35mm |
| WLL | 0.7t |
| Finish | Zinc Dichromate |
| Weight | 0.24kg |
| Size (mm) | 16mm |
| Thread Size | 16mm |
| Transverse Load Tonne | 0.17 |
About this product
The Beaver Metric Shouldered Eye Nut 16mm gives you a threaded lifting point on a stud or bolt, rated to 700kg (0.7t) in a straight vertical pull. The 16mm metric thread sits in the middle of the range, so it suits jobs where a smaller eye nut is short on capacity but you don't need to step up to the heavier sizes. Rated to DIN 582.
Dimensions are 61mm high and 63mm wide, with a 35mm eye and 13mm eye section, and it weighs 0.24kg. The shoulder seats flat against the load, which matters if the pull ever comes off vertical, transverse load limit is 0.17 tonne. Zinc dichromate finish handles general site knocks and moisture. Check the thread and eye for wear or deformation before each lift.
Common questions
- what is the WLL of a 16mm eye nut
- This size is rated to a working load limit of 700kg, or 0.7t, for a vertical lift. Transverse loading drops that to 0.17 tonne.
- beaver eye nut 16mm thread size and dimensions
- The thread is 16mm metric. Overall it measures 61mm high and 63mm wide with a 35mm eye diameter, and it weighs 0.24kg.
- what standard are beaver eye nuts rated to
- This eyenut is rated to DIN 582. Beaver also offers the range in BSW and UNC threads as well as metric.
Full specifications
| Product Code | Size (mm) | WLL | Transverse Load Tonne | Finish | Weight |
|---|---|---|---|---|---|
| 359208 | 8mm | 0.14t | 0.03 | Zinc Dichromate | 0.05kg |
| 359210 | 10mm | 0.23t | 0.06 | Zinc Dichromate | 0.09kg |
| 359212 | 12mm | 0.3t | 0.07 | Zinc Dichromate | 0.16kg |
| 359216 | 16mm | 0.7t | 0.17 | Zinc Dichromate | 0.24kg |
| 359220 | 20mm | 1.2t | 0.3 | Zinc Dichromate | 0.36kg |
| 359222 | 22mm | 1.5t | 0.37 | Zinc Dichromate | 0.58kg |
| 359224 | 24mm | 1.8t | 0.45 | Zinc Dichromate | 0.72kg |
| Product Code | Size (mm) | W | H | D1 | D2 | D3 | D4 | E |
|---|---|---|---|---|---|---|---|---|
| 359208 | 8mm | 36mm | 36mm | 20mm | 8mm | 8mm | 20mm | 8.5mm |
| 359210 | 10mm | 45mm | 45mm | 25mm | 10mm | 10mm | 25mm | 10mm |
| 359212 | 12mm | 54mm | 52mm | 30mm | 12mm | 12mm | 30mm | 11mm |
| 359216 | 16mm | 63mm | 61mm | 35mm | 16mm | 14mm | 35mm | 13mm |
| 359220 | 20mm | 72mm | 70mm | 40mm | 20mm | 16mm | 40mm | 16mm |
| 359222 | 22mm | 81mm | 80mm | 45mm | 22mm | 18mm | 45mm | 19.4mm |
| 359224 | 24mm | 90mm | 90mm | 50mm | 24mm | 20mm | 50mm | 20mm |
