Beaver Metric Shouldered Eye Nuts 12mm
359212per Each
$2.95 inc GSTTrade $2.66, save $0.29Trade accounts save 10%. Apply with your ABN
| E | 11mm |
| H | 52mm |
| W | 54mm |
| D1 | 30mm |
| D2 | 12mm |
| D3 | 12mm |
| D4 | 30mm |
| WLL | 0.3t |
| Finish | Zinc Dichromate |
| Weight | 0.16kg |
| Size (mm) | 12mm |
| Thread Size | 12mm |
| Transverse Load Tonne | 0.07 |
About this product
The Beaver Metric Shouldered Eye Nut 12mm is a threaded lifting point that screws onto a 12mm stud or bolt to give you an anchor for a hook, shackle or sling. It carries a working load limit of 0.3t, or 300kg, with a transverse load rating of 0.07 tonne when the pull comes off the vertical. This is the 12mm thread size in the range, the one you reach for on lighter loads where a bigger eye nut is overkill.
The eye measures 30mm inside with 11mm section, and the body stands 52mm tall and 54mm wide, so there is room for a decent hook bite. Zinc dichromate finish keeps surface rust off in the yard. At 0.16kg it is easy to carry a few spares. Rated to DIN 582. Always seat the shoulder flush against the load face and load it in line where you can.
Common questions
- what is the WLL of a 12mm eye nut
- This Beaver 12mm eye nut has a working load limit of 0.3t, which is 300kg. Transverse loading drops it to 0.07 tonne.
- beaver eye nut 12mm thread size and dimensions
- The thread is 12mm, with a 30mm inside eye diameter, 11mm eye section, 52mm height and 54mm width.
- what finish do beaver metric eye nuts have
- They come in a zinc dichromate finish, which helps keep surface corrosion down in normal site and yard conditions.
Full specifications
| Product Code | Size (mm) | WLL | Transverse Load Tonne | Finish | Weight |
|---|---|---|---|---|---|
| 359208 | 8mm | 0.14t | 0.03 | Zinc Dichromate | 0.05kg |
| 359210 | 10mm | 0.23t | 0.06 | Zinc Dichromate | 0.09kg |
| 359212 | 12mm | 0.3t | 0.07 | Zinc Dichromate | 0.16kg |
| 359216 | 16mm | 0.7t | 0.17 | Zinc Dichromate | 0.24kg |
| 359220 | 20mm | 1.2t | 0.3 | Zinc Dichromate | 0.36kg |
| 359222 | 22mm | 1.5t | 0.37 | Zinc Dichromate | 0.58kg |
| 359224 | 24mm | 1.8t | 0.45 | Zinc Dichromate | 0.72kg |
| Product Code | Size (mm) | W | H | D1 | D2 | D3 | D4 | E |
|---|---|---|---|---|---|---|---|---|
| 359208 | 8mm | 36mm | 36mm | 20mm | 8mm | 8mm | 20mm | 8.5mm |
| 359210 | 10mm | 45mm | 45mm | 25mm | 10mm | 10mm | 25mm | 10mm |
| 359212 | 12mm | 54mm | 52mm | 30mm | 12mm | 12mm | 30mm | 11mm |
| 359216 | 16mm | 63mm | 61mm | 35mm | 16mm | 14mm | 35mm | 13mm |
| 359220 | 20mm | 72mm | 70mm | 40mm | 20mm | 16mm | 40mm | 16mm |
| 359222 | 22mm | 81mm | 80mm | 45mm | 22mm | 18mm | 45mm | 19.4mm |
| 359224 | 24mm | 90mm | 90mm | 50mm | 24mm | 20mm | 50mm | 20mm |
Questions about this equipment? Send us a message and we’ll check it against the job.
