Beaver Metric Shouldered Eye Nuts 10mm
359210per Each
$2.15 inc GSTTrade $1.94, save $0.21Trade accounts save 10%. Apply with your ABN
| E | 10mm |
| H | 45mm |
| W | 45mm |
| D1 | 25mm |
| D2 | 10mm |
| D3 | 10mm |
| D4 | 25mm |
| WLL | 0.23t |
| Finish | Zinc Dichromate |
| Weight | 0.09kg |
| Size (mm) | 10mm |
| Thread Size | 10mm |
| Transverse Load Tonne | 0.06 |
About this product
The Beaver Metric Shouldered Eye Nuts 10mm is a threaded lifting point that screws onto an M10 stud or bolt to give you a rated eye for slings, shackles or hooks. It is the smallest thread in the range, with a working load limit of 230kg and a transverse load rating of 0.06 tonne. The eye stands 45mm high and 45mm wide, with a 25mm eye diameter and a 10mm section through the ring.
Zinc dichromate finish gives it a measure of corrosion resistance for workshop and site use. At 0.09kg it is light enough to keep a few in the toolbox for smaller jigs, panels and machine components. The shoulder needs to seat flush against the load face, so check the mating surface is flat and the thread is fully engaged before you take up any load. This eyenut is rated to DIN 582.
Common questions
- what is the WLL of a 10mm eye nut
- The 10mm Beaver metric shouldered eye nut has a working load limit of 230kg, or 0.23t. Transverse loading drops that to 0.06 tonne.
- what thread does the beaver 10mm eye nut take
- It has a 10mm metric thread, so it suits an M10 stud or bolt. Beaver also make this style in BSW and UNC threads.
- are zinc dichromate eye nuts ok outdoors
- The zinc dichromate finish offers some corrosion resistance, which handles general site and workshop conditions. Inspect it regularly and keep the thread clean and undamaged.
Full specifications
| Product Code | Size (mm) | WLL | Transverse Load Tonne | Finish | Weight |
|---|---|---|---|---|---|
| 359208 | 8mm | 0.14t | 0.03 | Zinc Dichromate | 0.05kg |
| 359210 | 10mm | 0.23t | 0.06 | Zinc Dichromate | 0.09kg |
| 359212 | 12mm | 0.3t | 0.07 | Zinc Dichromate | 0.16kg |
| 359216 | 16mm | 0.7t | 0.17 | Zinc Dichromate | 0.24kg |
| 359220 | 20mm | 1.2t | 0.3 | Zinc Dichromate | 0.36kg |
| 359222 | 22mm | 1.5t | 0.37 | Zinc Dichromate | 0.58kg |
| 359224 | 24mm | 1.8t | 0.45 | Zinc Dichromate | 0.72kg |
| Product Code | Size (mm) | W | H | D1 | D2 | D3 | D4 | E |
|---|---|---|---|---|---|---|---|---|
| 359208 | 8mm | 36mm | 36mm | 20mm | 8mm | 8mm | 20mm | 8.5mm |
| 359210 | 10mm | 45mm | 45mm | 25mm | 10mm | 10mm | 25mm | 10mm |
| 359212 | 12mm | 54mm | 52mm | 30mm | 12mm | 12mm | 30mm | 11mm |
| 359216 | 16mm | 63mm | 61mm | 35mm | 16mm | 14mm | 35mm | 13mm |
| 359220 | 20mm | 72mm | 70mm | 40mm | 20mm | 16mm | 40mm | 16mm |
| 359222 | 22mm | 81mm | 80mm | 45mm | 22mm | 18mm | 45mm | 19.4mm |
| 359224 | 24mm | 90mm | 90mm | 50mm | 24mm | 20mm | 50mm | 20mm |
