Beaver Metric Shouldered Eye Nuts 8mm
359208per Each
$1.13 inc GSTTrade $1.02, save $0.11Trade accounts save 10%. Apply with your ABN
| E | 8.5mm |
| H | 36mm |
| W | 36mm |
| D1 | 20mm |
| D2 | 8mm |
| D3 | 8mm |
| D4 | 20mm |
| WLL | 0.14t |
| Finish | Zinc Dichromate |
| Weight | 0.05kg |
| Size (mm) | 8mm |
| Thread Size | 8mm |
| Transverse Load Tonne | 0.03 |
About this product
The Beaver Metric Shouldered Eye Nuts 8mm gives you a threaded lifting point on an M8 stud or bolt, ready to take a hook, shackle or sling. This is the smallest thread in the range, rated to a working load limit of 140kg, or 0.14t, in a straight vertical pull. Transverse loading drops that right back to 0.03t, so keep the pull in line with the eye wherever you can.
Body dimensions are 36mm high and 36mm wide, with a 20mm eye and an 8.5mm section through the ring. The zinc dichromate finish gives it a bit of corrosion resistance on site, and at 0.05kg it is easy to carry a few spares. Rated to DIN 582. Make sure the shoulder seats flat and hard against the load face before you take up any weight.
Common questions
- what is the WLL of an 8mm eye nut
- The 8mm Beaver shouldered eye nut has a working load limit of 140kg, which is 0.14t, on a vertical lift. Loaded transversely it drops to 0.03t.
- what thread does the beaver 8mm eye nut take
- It has an 8mm metric thread. Beaver also make these eyebolts and eyenuts in BSW and UNC threads if metric is not what you need.
- are beaver eye nuts rated to a standard
- Yes, this eyenut is rated to DIN 582.
Full specifications
| Product Code | Size (mm) | WLL | Transverse Load Tonne | Finish | Weight |
|---|---|---|---|---|---|
| 359208 | 8mm | 0.14t | 0.03 | Zinc Dichromate | 0.05kg |
| 359210 | 10mm | 0.23t | 0.06 | Zinc Dichromate | 0.09kg |
| 359212 | 12mm | 0.3t | 0.07 | Zinc Dichromate | 0.16kg |
| 359216 | 16mm | 0.7t | 0.17 | Zinc Dichromate | 0.24kg |
| 359220 | 20mm | 1.2t | 0.3 | Zinc Dichromate | 0.36kg |
| 359222 | 22mm | 1.5t | 0.37 | Zinc Dichromate | 0.58kg |
| 359224 | 24mm | 1.8t | 0.45 | Zinc Dichromate | 0.72kg |
| Product Code | Size (mm) | W | H | D1 | D2 | D3 | D4 | E |
|---|---|---|---|---|---|---|---|---|
| 359208 | 8mm | 36mm | 36mm | 20mm | 8mm | 8mm | 20mm | 8.5mm |
| 359210 | 10mm | 45mm | 45mm | 25mm | 10mm | 10mm | 25mm | 10mm |
| 359212 | 12mm | 54mm | 52mm | 30mm | 12mm | 12mm | 30mm | 11mm |
| 359216 | 16mm | 63mm | 61mm | 35mm | 16mm | 14mm | 35mm | 13mm |
| 359220 | 20mm | 72mm | 70mm | 40mm | 20mm | 16mm | 40mm | 16mm |
| 359222 | 22mm | 81mm | 80mm | 45mm | 22mm | 18mm | 45mm | 19.4mm |
| 359224 | 24mm | 90mm | 90mm | 50mm | 24mm | 20mm | 50mm | 20mm |
