Beaver Lifting Collared Eyebolts Large Eye with Metric Thread DIN580 16mm

About this product

The Beaver Lifting Collared Eyebolt Large Eye with Metric Thread in 16mm gives you a screw-in lifting point on machinery, dies, motors and fabricated parts. It carries a working load limit of 0.7t in a straight vertical pull, with a 16mm thread and a 35mm collar that seats flat against the mounting face. Eye width is 63mm across, overall height 61mm, and the whole thing weighs 0.28kg.

This size sits in the middle of the range, so it suits gear too heavy for the smaller threads but well under a tonne. Transverse loading is rated at 0.17 tonne, so keep the pull in line with the bolt where you can. The zinc dichromate finish helps hold off surface rust on site. Check the thread and seating face are clean and the collar pulls up tight before every lift.
