Beaver G70 Gold Clevis Lug Link 10mm
353010per Each
$14.65 inc GSTTrade $13.19, save $1.46Trade accounts save 10%. Apply with your ABN
| LC | 6000kg |
| UOM | Each |
| b mm | 86.5 |
| d mm | 12.5 |
| e mm | 107.25 |
| f mm | 12.5 |
| h mm | 141.7 |
| s mm | 16.25 |
| d2 mm | 24 |
| h2 mm | 78 |
| Weight | 0.6kg |
| Chain Size | 10mm |
| Chain Size mm | 10 |
About this product
The Beaver G70 Gold Clevis Lug Link 10mm is a load restraint fitting that connects 10mm lashing chain back to a rated anchor point or winch lug on a truck or trailer. It carries a lashing capacity of 6000kg, which makes it the heaviest of the three sizes in this range and the one to reach for when you are tying down plant, steel or machinery on 10mm chain.
Grade 70 hi tensile construction, finished in zinc di-chromate for that gold look that tells a load inspector at a glance what grade you are running. Key dimensions are 141.7mm overall height, 86.5mm across the body, 12.5mm clevis pin diameter and 16.25mm at s, with the unit weighing 0.6kg. Made to AS/NZS 4344. Check the pin and clevis for wear or spread before every trip.
Common questions
- what is the LC of a 10mm G70 clevis lug link
- This 10mm Beaver clevis lug link has a lashing capacity of 6000kg. It is matched to 10mm grade 70 lashing chain.
- why are G70 load restraint fittings gold
- The gold colour comes from a zinc di-chromate finish, which is the standard way grade 70 restraint gear is identified on site and during load checks.
- what chain size does the Beaver clevis lug link 10mm suit
- It is sized for 10mm chain, the largest of the three sizes in the Beaver G70 Gold Clevis Lug Link range, with a 12.5mm clevis pin.
Full specifications
| Product Code | Chain Size mm | f mm | d mm | e mm | h mm | h2 mm | b mm | s mm | d2 mm | LC | Weight | UOM |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 353008 | 7-8 | 12.5 | 10 | 108.5 | 141.7 | 78 | 86.5 | 16.25 | 24 | 3800kg | 0.5kg | Each |
| 353010 | 10 | 12.5 | 12.5 | 107.25 | 141.7 | 78 | 86.5 | 16.25 | 24 | 6000kg | 0.6kg | Each |
| 353013 | 13 | 16.6 | 16 | 127.2 | 169 | 95.5 | 100.4 | 18.6 | 33 | 9000kg | 1.5kg | Each |
Questions about this equipment? Send us a message and we’ll check it against the job.
