Beaver G70 Gold Clevis Lug Link 7-8mm
353008per Each
$13.58 inc GSTTrade $12.22, save $1.36Trade accounts save 10%. Apply with your ABN
| LC | 3800kg |
| UOM | Each |
| b mm | 86.5 |
| d mm | 10 |
| e mm | 108.5 |
| f mm | 12.5 |
| h mm | 141.7 |
| s mm | 16.25 |
| d2 mm | 24 |
| h2 mm | 78 |
| Weight | 0.5kg |
| Chain Size | 7-8mm |
| Chain Size mm | 7-8 |
About this product
The Beaver G70 Gold Clevis Lug Link is the connecting point between your lashing chain and the anchor or winch on the trailer. This size takes 7-8mm chain and carries a lashing capacity of 3800kg, making it the middle option in the range for general truck and float work. Grade 70 hi tensile through the body, with a 10mm pin and 16.25mm inside width at the clevis.
Overall length is 141.7mm, with a 108.5mm lug and 12.5mm thickness at the load bearing section, so it sits flat against the deck without fouling the chain. The zinc di-chromate gold finish gives it corrosion resistance and makes it easy to pick out as restraint gear rather than lifting gear. Manufactured to AS/NZS 4344. Check the pin and body for wear, bending or cracks before each trip.
Common questions
- What size chain does the Beaver G70 gold clevis lug link 7-8mm suit?
- It suits 7-8mm lashing chain, with a 10mm pin and 16.25mm width across the clevis jaw.
- What is the lashing capacity of the 7-8mm G70 clevis lug link?
- The lashing capacity is 3800kg. It is load restraint rated, not a lifting fitting.
- Why is the Beaver clevis lug link gold?
- The gold colour comes from the zinc di-chromate finish, which adds corrosion resistance and helps identify Grade 70 restraint gear at a glance.
Full specifications
| Product Code | Chain Size mm | f mm | d mm | e mm | h mm | h2 mm | b mm | s mm | d2 mm | LC | Weight | UOM |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 353008 | 7-8 | 12.5 | 10 | 108.5 | 141.7 | 78 | 86.5 | 16.25 | 24 | 3800kg | 0.5kg | Each |
| 353010 | 10 | 12.5 | 12.5 | 107.25 | 141.7 | 78 | 86.5 | 16.25 | 24 | 6000kg | 0.6kg | Each |
| 353013 | 13 | 16.6 | 16 | 127.2 | 169 | 95.5 | 100.4 | 18.6 | 33 | 9000kg | 1.5kg | Each |
Questions about this equipment? Send us a message and we’ll check it against the job.
