Beaver G70 Ratched-Type Loadbinder with Eye Claw Hooks 7-8mm
344108per Each
$87.49 inc GSTTrade $78.74, save $8.75Trade accounts save 10%. Apply with your ABN
| UOM | Each |
| a mm | 355 |
| b mm | 32.5 |
| c mm | 65 |
| d mm | 9.5 |
| LC (kg) | 3800 |
| e Open mm | 773 |
| f Open mm | 831 |
| Chain Size | 7-8mm |
| Weight (kg) | 4.9 |
| e Closed mm | 609 |
| f Closed mm | 667 |
| Chain Size and Description | 7-8mm c/w eye claw hooks |
About this product
The Beaver G70 Ratched-Type Loadbinder with Eye Claw Hooks 7-8mm tensions transport chain over a load on a truck or trailer. It suits 7-8mm Grade 70 chain, the larger of the two sizes in the range, and carries a lashing capacity of 3800kg. The eye claw hooks seat straight into the chain links, so you are not fighting the hook to get a bite.
Ratchet action means you wind the tension on gradually and hold it, rather than throwing a lever over. Closed length runs 609mm at the eye and 667mm overall, opening out to 773mm and 831mm, giving you 164mm of take-up. Body is metal with a yellow painted finish for visibility on the deck. It weighs 4.9kg. Complies to AS/NZS 4344.
Common questions
- what chain size does the beaver 3800kg loadbinder suit
- This one is made for 7-8mm Grade 70 chain, fitted with eye claw hooks. Its lashing capacity is 3800kg.
- ratchet loadbinder vs lever loadbinder which is better
- A ratchet type like this lets you wind tension on in stages and hold it there, instead of forcing a lever handle over under full load.
- how much take up does this loadbinder have
- It measures 609mm closed and 773mm open at the eye, so you get 164mm of adjustment. Overall length runs 667mm closed to 831mm open.
Full specifications
| Product Code | Chain Size and Description | f Closed mm | e Closed mm | d mm | b mm | a mm | f Open mm | e Open mm | c mm | LC (kg) | Weight (kg) | UOM |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 344108 | 7-8mm c/w eye claw hooks | 667 | 609 | 9.5 | 32.5 | 355 | 831 | 773 | 65 | 3800 | 4.9 | Each |
| 344110 | 10mm c/w eye claw hooks | 712 | 644 | 11.5 | 32.5 | 355 | 877 | 809 | 65 | 6000 | 5.3 | Each |
Questions about this equipment? Send us a message and we’ll check it against the job.
