Beaver Forged Stub and Stub Commercial Turnbuckles - Galvanised 22mm

About this product

The Beaver Forged Stub and Stub Commercial Turnbuckles - Galvanised 22mm is a weldable tensioner for straight or inline tension jobs. Both ends are plain stubs, so you weld on whatever fitting your setup calls for instead of working around a fixed eye or hook. This is the 22mm thread size, the heavier end of the range at 2.46kg, with a body length of 320mm and take-up from 585mm closed out to 800mm open.

Built from forged steel, so it handles the load of a permanent tensioning system rather than a temporary one. The hot dipped galvanised finish keeps rust off the threads and body, which matters on fixed installs that sit outside for years. Key dimensions are L 320mm, L1 270mm and L2 140mm, worth checking against your frame before you cut and weld. Smaller sizes in the range suit lighter tension work.
