Beaver Forged Stub and Stub Commercial Turnbuckles - Galvanised 16mm

About this product

The Beaver Forged Stub and Stub Commercial Turnbuckle in 16mm is a weld-on tensioner for straight, inline pulls where you want to build the end fittings to suit the job. Both ends are plain stubs, so you can weld on eyes, plates or whatever the setup calls for. This size takes a 16mm thread and runs 500mm closed, opening out to 682mm, which gives you a solid take-up range on longer runs.

Body length is 250mm, with L1 at 240mm and L2 at 115mm, and the whole unit weighs about 1kg, so it handles easily during fit-up. It is forged steel throughout, then hot dipped galvanised to hold off rust and corrosion on outdoor and site work. A sensible mid-size pick when the smaller threads are light on adjustment and the bigger ones are more turnbuckle than the job needs.
