Beaver Commercial Galvanised Wire Rope Grips (Pail) 10mm
301210Pper Pail
$39.29 inc GSTTrade $35.36, save $3.93Trade accounts save 10%. Apply with your ABN
| A | 16mm |
| B | 18mm |
| C | 18.5mm |
| D | 8mm |
| H | 34mm |
| W | 33mm |
| Finish | Electro Galvanised |
| Pail QTY | 50 |
| Wire Diameter | 10mm |
About this product
Beaver Commercial Galvanised Wire Rope Grips in the 10mm size are for clamping and terminating 10mm wire rope on non-lifting jobs. The 8mm U-bolt and 16mm saddle width suit the rope diameter, with a 34mm height and 33mm width across the body, so you can work out clearance before you start making up your terminations.
The electro galvanised finish gives a bit of protection against surface rust on general site and yard work. Note that these grips are not suitable for lifting, so keep them to fencing, guy lines, bracing and similar static duties. Fit them the right way round with the saddle on the live end, space them correctly along the rope, and check the nuts for tension after the rope has taken load and settled.
Common questions
- can beaver galvanised wire rope grips be used for lifting
- No. These grips are not suitable for lifting and should only be used on non-lifting applications.
- what size wire rope do 10mm rope grips fit
- This size is made for 10mm wire rope, with a 16mm saddle width and an 8mm U-bolt.
- what finish do these wire rope grips have
- They are electro galvanised, which gives some protection against surface rust in general site and yard conditions.
Full specifications
| Product code | Wire Diameter | W | C | H | A | D | B | Finish | Pail QTY |
|---|---|---|---|---|---|---|---|---|---|
| 301203P | 3mm | 19.5mm | 9mm | 17mm | 9.5mm | 4mm | 10.5mm | Electro Galvanised | 100 |
| 301205P | 5mm | 22.5mm | 11mm | 19mm | 10mm | 5mm | 11mm | Electro Galvanised | 100 |
| 301206P | 6mm | 24mm | 13mm | 23mm | 10.5mm | 5mm | 12mm | Electro Galvanised | 50 |
| 301208P | 8mm | 28mm | 15mm | 28mm | 14mm | 6mm | 14mm | Electro Galvanised | 80 |
| 301210P | 10mm | 33mm | 18.5mm | 34mm | 16mm | 8mm | 18mm | Electro Galvanised | 50 |
| 301213P | 13mm | 41mm | 23mm | 45mm | 21mm | 10mm | 22mm | Electro Galvanised | 20 |
| 301216P | 16mm | 49mm | 29.5mm | 52mm | 25mm | 12mm | 25mm | Electro Galvanised | 15 |
| 301220P | 20mm | 52mm | 32mm | 62mm | 30mm | 12mm | 28mm | Electro Galvanised | 10 |
| 301222P | 22mm | 61mm | 37mm | 68mm | 34mm | 14mm | 33mm | Electro Galvanised | 5 |
| 301225P | 25mm | 70mm | 41mm | 78mm | 39mm | 14mm | 34mm | Electro Galvanised | 5 |
