Beaver Commercial Galvanised Wire Rope Grips (Pail) 8mm
301208Pper Pail
$39.11 inc GSTTrade $35.20, save $3.91Trade accounts save 10%. Apply with your ABN
| A | 14mm |
| B | 14mm |
| C | 15mm |
| D | 6mm |
| H | 28mm |
| W | 28mm |
| Finish | Electro Galvanised |
| Pail QTY | 80 |
| Wire Diameter | 8mm |
About this product
Beaver Commercial Galvanised Wire Rope Grips in the 8mm size clamp the tail of 8mm wire rope back on itself to form a secure eye or termination. This is the mid-range size in the Beaver commercial grip family, matched to 8mm rope and no other diameter, so check your rope gauge before you order. The saddle measures 28mm across and 28mm high, with 14mm A and B dimensions, a 15mm C and a 6mm D.
Finish is electro galvanised, which gives the U-bolt and saddle a basic barrier against surface rust in general outdoor work. Worth being clear on one point: these grips are not suitable for lifting. Use them for fencing, guy lines, bracing and similar static jobs. Fit the saddle on the live end of the rope, keep the U-bolt on the dead tail, and nip the nuts down evenly.
Common questions
- can beaver galvanised wire rope grips be used for lifting
- No. These wire rope grips are not suitable for lifting and should only be used on non-lifting applications.
- what size wire rope does the 301208P grip fit
- This grip is made for 8mm wire rope. Other sizes in the Beaver commercial range cover different rope diameters.
- what finish do these wire rope grips have
- They are electro galvanised, which gives the saddle and U-bolt some protection against surface rust in general outdoor use.
Full specifications
| Product code | Wire Diameter | W | C | H | A | D | B | Finish | Pail QTY |
|---|---|---|---|---|---|---|---|---|---|
| 301203P | 3mm | 19.5mm | 9mm | 17mm | 9.5mm | 4mm | 10.5mm | Electro Galvanised | 100 |
| 301205P | 5mm | 22.5mm | 11mm | 19mm | 10mm | 5mm | 11mm | Electro Galvanised | 100 |
| 301206P | 6mm | 24mm | 13mm | 23mm | 10.5mm | 5mm | 12mm | Electro Galvanised | 50 |
| 301208P | 8mm | 28mm | 15mm | 28mm | 14mm | 6mm | 14mm | Electro Galvanised | 80 |
| 301210P | 10mm | 33mm | 18.5mm | 34mm | 16mm | 8mm | 18mm | Electro Galvanised | 50 |
| 301213P | 13mm | 41mm | 23mm | 45mm | 21mm | 10mm | 22mm | Electro Galvanised | 20 |
| 301216P | 16mm | 49mm | 29.5mm | 52mm | 25mm | 12mm | 25mm | Electro Galvanised | 15 |
| 301220P | 20mm | 52mm | 32mm | 62mm | 30mm | 12mm | 28mm | Electro Galvanised | 10 |
| 301222P | 22mm | 61mm | 37mm | 68mm | 34mm | 14mm | 33mm | Electro Galvanised | 5 |
| 301225P | 25mm | 70mm | 41mm | 78mm | 39mm | 14mm | 34mm | Electro Galvanised | 5 |
Questions about this equipment? Send us a message and we’ll check it against the job.
