Beaver Vertical Drum Lifting Clamps 0.5t
262500per Each
$137.43 inc GSTTrade $123.69, save $13.74Trade accounts save 10%. Apply with your ABN
| H | 470mm |
| WLL | 0.5t |
| Type | Vertical |
| Weight | 5kg |
| L (Drum Size) | 200L |
| Working Load Limit | 0.5t |
About this product
The Beaver Vertical Drum Lifting Clamps 0.5t is a lifting clamp for picking up lidded drums in the upright position. It grips the rolled rim of the drum, so the load stays vertical from hook-up to set-down. With a working load limit of 0.5t, it covers a full 200L drum of most liquids without fuss.
Body is high tensile steel and the clamp stands 470mm tall, at a handy 5kg for one person to fit and move around site. Because it is a vertical clamp, it suits drums that need to stay on their base, not drums being tipped or decanted. The drum must have a lid for the clamp to bite on. Complies to AS 4991. Check the jaw and rim contact area for wear or spread before every lift.
Common questions
- what size drum does the beaver 0.5t drum clamp fit
- It is made for drums up to 200L. The drum needs a lid, since the clamp grips the rim.
- how much can a beaver vertical drum lifting clamp lift
- The working load limit is 0.5t. Do not exceed that, including the weight of the drum itself and its contents.
- what is the difference between a vertical and horizontal drum clamp
- This one is a vertical type, so the drum stays upright through the lift. A horizontal clamp is for drums being handled on their side, which this clamp is not built for.
Full specifications
| Product Code | WLL | Type | L (Drum Size) | H | Weight |
|---|---|---|---|---|---|
| 262500 | 0.5t | Vertical | 200L | 470mm | 5kg |
