Beaver VC Vertical Plate Clamp 1t
261130per Each
$154.00 inc GSTTrade $138.60, save $15.40Trade accounts save 10%. Apply with your ABN
| WLL | 1t |
| B (mm) | 144 |
| C (mm) | 68 |
| D (mm) | 286 |
| E (mm) | 55 |
| Working Load Limit | 1t |
| A Jaw Openings (mm) | 0-30 |
| Net Weight Per Pair (kg) | 4.5kg/pc |
About this product
The Beaver VC Vertical Plate Clamp 1t is a lifting clamp for picking up and turning steel plate, girders, beams and pipe. This is the smallest size in the range, with a 1t working load limit and a jaw opening of 0 to 30mm, so it suits thinner plate work rather than heavy slab. Overall it measures 286mm at D and 144mm at B, at 4.5kg per clamp.
Grip comes from a positive cam action that bites harder as the load comes on, with clamping force increasing in ratio to the weight lifted. The cam and jaws are drop forged and heat treated alloy steel in a heavy duty steel body, and a spring loaded safety lock holds the jaw shut before the lift starts. Proof load tested at manufacture and complies to AS4991.
Common questions
- what thickness plate will the beaver 1t vertical clamp take
- The jaw opening is 0 to 30mm, so it handles plate up to 30mm thick within the 1t working load limit.
- how much does the beaver vc 1t plate clamp weigh
- 4.5kg per clamp, which makes it easy enough to handle and position by hand on site.
- is the beaver vc vertical plate clamp certified
- It complies to AS4991 and is proof load tested at the time of manufacture.
Full specifications
| Product Code | WLL | A Jaw Openings (mm) | B (mm) | C (mm) | D (mm) | E (mm) | Net Weight Per Pair (kg) |
|---|---|---|---|---|---|---|---|
| 261130 | 1t | 0-30 | 144 | 68 | 286 | 55 | 4.5kg/pc |
| 261240 | 2t | 0-40 | 170 | 82.5 | 297 | 60 | 7.5kg/pc |
| 261350 | 3t | 0-50 | 210 | 99.5 | 336 | 60 | 14.0kg/pc |
Questions about this equipment? Send us a message and we’ll check it against the job.
