Beaver Grade S Safety Pin Bow Shackle 25t

About this product

The Beaver Grade S Safety Pin Bow Shackle 25t is the heavy end of the range, built for lifts where a screw pin just will not do. At 45mm x 51mm with a 25t working load limit, it takes the big slings and multi-leg arrangements that smaller sizes cannot handle. The bolt, nut and cotter arrangement stays put, so it suits long-term or permanent rigging and any job where the load can slide on the pin and turn it.

Inside width is 73mm and inside length 178mm, with a 127mm bow and a 110mm boss, giving plenty of room for thick soft slings or several legs at once. It weighs 14.99kg, so plan the handling. Hot dip galvanised for corrosion protection, marked with WLL, quality grade, size and batch ID or date of manufacture. Proof tested to the Australian Standard and complies to AS 2741, with test certificates available on request.
