Beaver Grade S Safety Pin Bow Shackle 9.5t
244329per Each
$54.27 inc GSTTrade $48.84, save $5.43Trade accounts save 10%. Apply with your ABN
| WLL | 9.5t |
| Size | 29mm x 32mm |
| Type | Grade S |
| Shape | Bow |
| Weight | 3.87kg |
| Diameter | 29mm |
| Closing Method | Safety Pin |
| Inside Width (W) | 46mm |
| Pin Diameter (D) | 32mm |
| Width of Bow (B) | 74mm |
| Diameter Boss (F) | 67mm |
| Inside Length (L) | 108mm |
| Working Load Limit | 9.5t |
About this product
The Beaver Grade S Safety Pin Bow Shackle 9.5t is a bolt, nut and cotter pin shackle for lifting and towing where the connection has to stay put. At 9.5t working load limit it sits in the heavier end of the range, with a 29mm body, 32mm pin diameter and 46mm inside width, so it takes chunky slings, thimbles and hooks without crowding. Inside length is 108mm, bow width 74mm and boss diameter 67mm, and the whole thing weighs 3.87kg.
The safety pin is the reason to pick this one over a screw pin. If the load can slide and rotate the pin, or the shackle is staying in place long term, the nut and cotter hold it together. Grade S steel handles the high strength work, and the hot dip galvanised finish deals with weather and site exposure. Each shackle is marked with WLL, grade, size and batch ID, proof tested to the Australian Standard, and complies to AS 2741. Test certificates available on request.
Common questions
- what is the wll of a 29mm bow shackle
- This Beaver Grade S bow shackle has a working load limit of 9.5t, with a 29mm body diameter and a 32mm pin.
- safety pin vs screw pin shackle which one do i need
- Go the safety pin version for long-term or permanent connections, or anywhere the load may slide and rotate the pin. The nut and cotter stop it backing off.
- are beaver grade s shackles australian standard compliant
- Yes, they are proof tested to the Australian Standard and comply to AS 2741, with test certificates available on request.
Full specifications
| Product Code | Size | WLL | Type | Shape | Closing Method | Weight |
|---|---|---|---|---|---|---|
| 244313 | 13mm x 16mm | 2t | Grade S | Bow | Safety Pin | 0.44kg |
| 244316 | 16mm x 19mm | 3.2t | Grade S | Bow | Safety Pin | 0.79kg |
| 244319 | 19mm x 22mm | 4.7t | Grade S | Bow | Safety Pin | 1.26kg |
| 244322 | 22mm x 25mm | 6.5t | Grade S | Bow | Safety Pin | 1.88kg |
| 244325 | 25mm x 29mm | 8.5t | Grade S | Bow | Safety Pin | 2.78kg |
| 244329 | 29mm x 32mm | 9.5t | Grade S | Bow | Safety Pin | 3.87kg |
| 244332 | 32mm x 35mm | 12t | Grade S | Bow | Safety Pin | 5.26kg |
| 244335 | 35mm x 38mm | 13.5t | Grade S | Bow | Safety Pin | 6.94kg |
| 244338 | 38mm x 41mm | 17t | Grade S | Bow | Safety Pin | 8.79kg |
| 244345 | 45mm x 51mm | 25t | Grade S | Bow | Safety Pin | 14.99kg |
| 244351 | 51mm x 57mm | 35t | Grade S | Bow | Safety Pin | 20.65kg |
| 244357 | 57mm x 63mm | 45t | Grade S | Bow | Safety Pin | 32.5kg |
| 244363 | 63mm x 70mm | 55t | Grade S | Bow | Safety Pin | 41.05kg |
| Product Code | Size | Diameter | Pin Diameter (D) | Inside Width (W) | Inside Length (L) | Width of Bow (B) | Diameter Boss (F) |
|---|---|---|---|---|---|---|---|
| 244313 | 13mm x 16mm | 13mm | 16mm | 21mm | 48mm | 33mm | 33mm |
| 244316 | 16mm x 19mm | 16mm | 19mm | 27mm | 61mm | 43mm | 40mm |
| 244319 | 19mm x 22mm | 19mm | 22mm | 32mm | 72mm | 51mm | 48mm |
| 244322 | 22mm x 25mm | 22mm | 25mm | 37mm | 84mm | 58mm | 54mm |
| 244325 | 25mm x 29mm | 25mm | 29mm | 43mm | 95mm | 68mm | 60mm |
| 244329 | 29mm x 32mm | 29mm | 32mm | 46mm | 108mm | 74mm | 67mm |
| 244332 | 32mm x 35mm | 32mm | 35mm | 52mm | 119mm | 83mm | 76mm |
| 244335 | 35mm x 38mm | 35mm | 38mm | 57mm | 133mm | 92mm | 84mm |
| 244338 | 38mm x 41mm | 38mm | 41mm | 60mm | 146mm | 98mm | 92mm |
| 244345 | 45mm x 51mm | 45mm | 51mm | 73mm | 178mm | 127mm | 110mm |
| 244351 | 51mm x 57mm | 51mm | 57mm | 83mm | 197mm | 146mm | 127mm |
| 244357 | 57mm x 63mm | 57mm | 63mm | 97mm | 218mm | 156mm | 136mm |
| 244363 | 63mm x 70mm | 63mm | 70mm | 105mm | 267mm | 184mm | 152mm |
Questions about this equipment? Send us a message and we’ll check it against the job.
