Beaver Yellow Pin Grade S Safety Pin Dee Shackle 3.2t
243316per Each
$10.44 inc GSTTrade $9.40, save $1.04Trade accounts save 10%. Apply with your ABN
| WLL | 3.2t |
| Size | 16mm x 19mm |
| Type | Grade S |
| Shape | Dee |
| Weight | 0.79kg |
| Diameter | 16mm |
| Closing Method | Safety Pin |
| Inside Width (W) | 27mm |
| Pin Diameter (D) | 19mm |
| Diameter Boss (F) | 40mm |
| Inside Length (L) | 51mm |
| Working Load Limit | 3.2t |
About this product
The Beaver Yellow Pin Grade S Safety Pin Dee Shackle 3.2t is a bolt, nut and cotter dee shackle for straight-line lifting jobs that stay rigged for the long haul. The 16mm body carries a 3.2t working load limit and takes a 19mm pin, with 27mm inside width and 51mm inside length to suit chain, eyes and slings. Hot dipped galvanised with the yellow painted pin, and it weighs 0.79kg.
Pick the safety pin version where the load can slide or rotate on the pin, or where gear vibrates and a screw pin could work loose. The pin can turn under load without backing out, and the cotter keeps it captive. Grade S gives good strength for the size, and the 40mm diameter boss spreads load through the eye. Complies to AS 2741.
Common questions
- what is the WLL of a 16mm dee shackle
- This Beaver Grade S dee shackle has a working load limit of 3.2t with a 16mm body diameter and 19mm pin.
- safety pin vs screw pin shackle which one do i need
- Go the safety pin for long-term or permanent rigging, loads that slide and rotate on the pin, or equipment that vibrates. A screw pin suits shackles you pull apart regularly.
- are beaver yellow pin shackles galvanised
- Yes, they are hot dipped galvanised with a yellow painted pin for easy identification.
Full specifications
| Product Code | Size | WLL | Type | Shape | Closing Method | Weight |
|---|---|---|---|---|---|---|
| 243313 | 13mm x 16mm | 2t | Grade S | Dee | Safety Pin | 0.44kg |
| 243316 | 16mm x 19mm | 3.2t | Grade S | Dee | Safety Pin | 0.79kg |
| 243319 | 19mm x 22mm | 4.7t | Grade S | Dee | Safety Pin | 1.26kg |
| 243322 | 22mm x 25mm | 6.5t | Grade S | Dee | Safety Pin | 1.88kg |
| 243325 | 25mm x 29mm | 8.5t | Grade S | Dee | Safety Pin | 2.78kg |
| 243332 | 32mm x 35mm | 12t | Grade S | Dee | Safety Pin | 5.26kg |
| Product Code | Size | Diameter | Pin Diameter (D) | Inside Width (W) | Inside Length (L) | Diameter Boss (F) |
|---|---|---|---|---|---|---|
| 243313 | 13mm x 16mm | 13mm | 16mm | 21mm | 41mm | 33mm |
| 243316 | 16mm x 19mm | 16mm | 19mm | 27mm | 51mm | 40mm |
| 243319 | 19mm x 22mm | 19mm | 22mm | 32mm | 60mm | 48mm |
| 243322 | 22mm x 25mm | 22mm | 25mm | 37mm | 71mm | 54mm |
| 243325 | 25mm x 29mm | 25mm | 29mm | 43mm | 81mm | 60mm |
| 243332 | 32mm x 35mm | 32mm | 35mm | 52mm | 100mm | 76mm |
Questions about this equipment? Send us a message and we’ll check it against the job.
