Beaver Hot Dipped Galvanised Screw Pin Dee Shackles (Pail) 1.5t
241311Pper Pail
$81.02 inc GSTTrade $72.92, save $8.10Trade accounts save 10%. Apply with your ABN
| WLL | 1.5t |
| Size | 11mm x 13mm |
| Diameter | 11mm |
| Bucket Weight | 4kg |
| QTY per Bucket | 20 |
| Shackle Colour | Hot Dipped Galvanised |
| Bucket Capacity | 2L |
| Inside Width (W) | 18mm |
| Pin Diameter (D) | 13mm |
| Diameter Boss (e) | 27mm |
| Inside Length (L) | 37mm |
| Working Load Limit | 1.5t |
About this product
The Beaver Hot Dipped Galvanised Screw Pin Dee Shackle in 1.5t is a straight-sided lifting shackle for in-line loads, sitting in the middle of the range where a 1t shackle is light on and a larger body starts getting clumsy in the hand. The body measures 11mm with a 13mm screw pin, giving an 18mm inside width and 37mm inside length for connecting slings, chain and hardware.
Grade S steel gives good strength for the size, and the hot dipped galvanised finish with its yellow painted pin holds up in the weather on mine sites and construction jobs. The 27mm boss carries the stamped rating, so crews can check it during pre-use inspection. Complies to AS 2741. Keep the pin fully seated and shoulder to shoulder before taking load, and pull in line with the body, not across the sides.
Common questions
- what is the WLL of a 1.5t dee shackle
- This shackle has a working load limit of 1.5t. That rating applies to in-line loading through the body, not side loading.
- beaver 1.5t dee shackle pin size
- The pin diameter is 13mm and the shackle body is 11mm, with an 18mm inside width and 37mm inside length.
- are galvanised shackles ok for mine sites
- Yes, the hot dipped galvanised finish with a yellow painted pin is made for outdoor work in mining and construction. Inspect the coating and pin threads regularly for damage.
- dee shackle or bow shackle for slings
- A dee shackle like this one suits straight in-line pulls, while a bow shackle handles multiple leg connections and wider angles.
Full specifications
| Product Code | Size | WLL | Shackle Colour | Bucket Capacity | QTY per Bucket | Bucket Weight |
|---|---|---|---|---|---|---|
| 241306P | 6mm x 8mm | 0.5t | Hot Dipped Galvanised | 2L | 100 | 2.8kg |
| 241308P | 8mm x 10mm | 0.75t | Hot Dipped Galvanised | 2L | 50 | 3.85kg |
| 241310P | 10mm x 11mm | 1t | Hot Dipped Galvanised | 2L | 30 | 3.9kg |
| 241311P | 11mm x 13mm | 1.5t | Hot Dipped Galvanised | 2L | 20 | 4kg |
| 241313P | 13mm x 16mm | 2t | Hot Dipped Galvanised | 2L | 14 | 4.2kg |
| 241316P | 16mm x 19mm | 3.2t | Hot Dipped Galvanised | 5L | 20 | 11.6kg |
| 241319P | 19mm x 22mm | 4.7t | Hot Dipped Galvanised | 5L | 10 | 10.2kg |
| 241322P | 22mm x 25mm | 6.5t | Hot Dipped Galvanised | 5L | 8 | 11.44kg |
| 241325P | 25mm x 29mm | 8.5t | Hot Dipped Galvanised | 5L | 4 | 8.62kg |
| Product Code | Size | Diameter | Pin Diameter (D) | Inside Width (W) | Inside Length (L) | Diameter Boss (e) |
|---|---|---|---|---|---|---|
| 241306P | 6mm x 8mm | 6mm | 8mm | 12mm | 22mm | 17mm |
| 241308P | 8mm x 10mm | 8mm | 10mm | 13mm | 26mm | 21mm |
| 241310P | 10mm x 11mm | 10mm | 11mm | 17mm | 32mm | 25mm |
| 241311P | 11mm x 13mm | 11mm | 13mm | 18mm | 37mm | 27mm |
| 241313P | 13mm x 16mm | 13mm | 16mm | 21mm | 41mm | 33mm |
| 241316P | 16mm x 19mm | 16mm | 19mm | 27mm | 51mm | 40mm |
| 241319P | 19mm x 22mm | 19mm | 22mm | 32mm | 60mm | 48mm |
| 241322P | 22mm x 25mm | 22mm | 25mm | 37mm | 71mm | 54mm |
| 241325P | 25mm x 29mm | 25mm | 29mm | 43mm | 81mm | 60mm |
